Archway Pass Walk Through Scanner Metal Detecting Equipment With Lcd Screen

Archway Pass Walk Through Scanner Metal Detecting Equipment With Lcd Screen

Advantages:

• High sensitivity, economic model
• Suit for Factories and Entertainment environments
• 6,12,18 zones adjustment

Technical specification :

• Electric current: AC100V~240V 50/60Hz
• Power: 10W
• Work environment: -20℃~+45℃
• Gross Weight: 70kg
• Outer frame: 2220mm (h) x 820mm (w) X 500mm (d)
• Inner frame: 2000mm (h) X 700mm (w) X 500mm (d)

Characteristic:

• 6/12/18 Pinpoint zones to precisely identify multiple target locations from head to toe
• Advanced broadband detection technology: can detect ferrous and non-ferrous articles.
• Sensitivity adjustable from Level 0 to 299 (300 levels)
• High: Can detect a pin
• Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes.
• Shock proof to avoid false alarm
• Sound and light alarm
• Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.
• Four LED light bars on both door panels: gives alarm corresponding to the height or human body.
• Tamper-Proof: operate program is protected by password.
• Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources
• Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity
• Harmless to pregnant woman and heart pacemaker.
• Modular structure to easy after service
• LCD display
•  Remote control unit ( Optional )
• Adjustable frequency & 8 different volume tunes

Standards:

• In accordance with: EN60950, WN50081-1, EN50082-1
• CE Certificate; ISO 9001:2008 Certificate, National standard
• National standard
