Product Details:
Payment & Shipping Terms:
|
| Detection Zones: | 8/16/24/33/45 Optional | MBSU Backup Battery: | Optional |
|---|---|---|---|
| Stock Available: | More Than 20 Units | Usage: | Security Inspection |
| Customized: | Yes | Color: | Gray |
| Type: | Walk Through Metal Detector Gate | Appication: | Museum, Prison, Pier, Station, School,Checkpoint,Court,Airport,Factory Etc. |
| Display: | LCD | Sensitivity: | 0-299 |
| Pacing Lights: | International Symbols Located At Entrance | Alarms: | Audible Tone And Volume Adjustable. Bright LED |
| Power: | 100 To 240VAC, 50 Or 60 Hertz, 45 Watts | Warranty: | 12 Months |
| Transport Package: | Carton Box | HS Code: | 8543709100 |
| High Light: | IP55 Walk Through Metal Detector,Shockproof Walk Through Metal Detector,MBSU Battery Arched Metal Detector |
||
33 Zones Airport Security Door Frame Metal Detector Archway Metal Detector
Metal detection equipment for people screening and loss prevention.
The walk through metal detector is of body height and with both sides' column aluminum alloy alarm indicators. With electromagnetic fields, metal items can be detected put carried by human when pass through the alarm device, items like various control tools, weapons, metal products, electronic products and other metal articles, etc..
As a anti-theft examination an effective tool, mainly used in government agencies, public security organs, prosecution, courts, prisons, detention centers, customs, airports, stations, stadiums, exhibition venues, entertainment, large gathering places, etc., as well as hardware, electronics, jewelry, military, Mint factories or businesses. to carry out security inspection.
Technical Specifications:
| Electrical current | AC100V~240V 50/60Hz |
| Power | 45W |
| Operating | -20℃~+45℃ |
| Storage | -40℃~+50℃ |
| Waterproo Level | IP55 |
| Gross Weight | 70kg |
| Alarm | Audible tone and volume adjustable. Bright LED visual alarm. |
| Outer frame | 2210mm (h) x 880mm (w) X 600mm (d) |
| Inner frame | 2010mm (h) X 760mm (w) X 600mm (d) |
Characteristic:
Self-diagnostic procedures
Input MBSU battery backup, in time power transfer
Modular structure easy for after sales service
Automatically adapt to the working environment
Auto scan environmental interference at site
LCD friendly operation interface for user
Operation way: remote control
Two or four LED light bars on both door panels: gives alarm corresponding to the height or human body.
Detect zone: single, 8,16,24zones(33,45zones optional)
Sensitivity adjustable from Level 0 to 300
High: Can detect a clip
Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes.
Shock proof to avoid false alarm
Sound and light alarm
Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.
Tamper-Proof: operate program is protected by password.
Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources.
Connect with computer, camera, turnstile(Optional)
Inner size as 76cm width(less false alarm for big body passagers)
Mix distance between two Walk-thru:0.3 meters at low sensitivity, 0.5meters at high sensitivity
Harmless to pregnant woman and heart pacemaker
Standards & Certificates:
CE
FCC
ROHS
ISO
