Multi - Language Handheld X-Ray Baggage Inspection System For Security Check

China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

Multi - Language Handheld X-Ray Baggage Inspection System For Security Check

Multi - Language Handheld X-Ray Baggage Inspection System For Security Check
Multi - Language Handheld X-Ray Baggage Inspection System For Security Check Multi - Language Handheld X-Ray Baggage Inspection System For Security Check Multi - Language Handheld X-Ray Baggage Inspection System For Security Check Multi - Language Handheld X-Ray Baggage Inspection System For Security Check

Large Image :  Multi - Language Handheld X-Ray Baggage Inspection System For Security Check

Product Details:
Place of Origin: China
Brand Name: SECUSCAN
Certification: CE, ISO, USFDA, Radiation Safety
Model Number: AT5030C
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Packing
Delivery Time: One week when there is stock, One month when no stock.
Payment Terms: T/T, L/C, Western Union
Supply Ability: 500 sets/month
Detailed Product Description
Tunnel Size: 500(W)*300(H)mm Conveyor Speed: 0.22m/s
Penetration: 30-32mm Steel Software Interface: Support Multi Language
Training: Free Of Cost At The Factory Weight: 350kgs
Warranty: One Year Free Spare Parts, Life Time Technic Support Operation: User Maual Attached With Machine
Installation: Very Easy OEM/ODM: Accepted
High Light:

cargo inspection

,

x-ray baggage inspection system

Handhold baggage and parcel inspection  scanner for security check

Model: AT-5030C



Applications:





End user Recommend X Ray Baggage Scanner model NO.
Airports, Transport terminals AT6040; AT6550; AT10080; AT100100
Factories (to find needle in clothing, shoes, bags), AT5030; AT6040; AT6550
Courthouses, Embassies, Buildings AT5030; AT6040; AT6550
Military installations AT5030;AT6040; AT6550; AT8065; AT100100
Prisons, Hotels, Schools, Convention centers AT5030; AT6040; AT6550; AT10080
Security checkpoints,Special events location AT5030; AT6040; AT6550; AT8065; AT10080





Advantages:

  • We have 40000 square meter factory, total more than 260 employess and 5 R&D team
  • We have passed ISO9001, 16001, OHSMS18001, Health Inspection
  • We have full security product line which can meet your different needs
  • We never stop researching and will have one or two new product each year
  • We listen to our customer and solve their problems

Specification:



X Ray Generator:



Beam direction Downward
Beam angle 80 degree
Anode voltage 140kv
Anode power 0.35mA
Cooling / Duty Cycle Oil Cooling /100%





General specification:



Tunnel Size 500(W)*300(H)mm
Conveyor Speed 0.22m/s
Conveyor Max Load 170kg
Spatial Resolution Level Dia1.0mm
Vertical esolution Level: Dia1.0mm
Vertical: Dial1.0mm
Penetrate resolution 30-32mm
Film Safety Guarantee ISO1600 Film
X-ray Leakage <0.5 μ Gy/h (at a distance of 5cm From external housing)





X Ray Image:



X-ray Sensor                       L-Shaped Photodiode Array, 12bit Deep
Monitor High Resolution Color, LCD Accord, 17 inch
Image Processing Edge enhancement, image strengthening, image lightening, , reducing darkening, image returning, image retrieval.
Image Grey Level 4096
Image Max Resolution 1024 * 1280 pixel
Image Processing 24bit for processing real time
Image storage Storage 60000 pictures in real time
Zoom 2, 4, 8, 16 , 32 Times Enlarge, Whole screen continuous observation







Packing and Shipment:





Packing details carton packing, two cartons
Carton size: (L)88*(W)88*(H)1430mm
Carton Size: (L)2380*(W)1120*(H)1660mm
Total Gross Weight:700kg
Payment terms T/T, Western Union, Cash,L/C
Shipping methods By air (5-7days, most expensive)
By express (3-7days, more expensive)

By sea (15-28days, cheapest)







Installation Data:



  1. Operation temperature/Humidity: 0º C-45º C/20%-95%(non-condensing)
  2. Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
  3. Operation Power: 220VAC(± 10%)50± 3Hz
  4. Power Consumption: 1.0 KW (max), 0.7KW(working)
  5. Noise: <58dB.



Our service:



  1. Operation training program for end users
  2. Free of factory training for engineer from agents to end user
  3. Provide on-site trainning when customer requires
  4. If quality problems happen in guarantee period, our company will maintain for free.
  5. One year free spare parts and life time technical support
  6. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
  7. If you are caught in some problems when using our products, welcome to contact us at any time.



Certification:



  1. CE Certificate
  2. ISO9001 Certificate
  3. ISO14001 Certificate
  4. OHSMS18001 Certificate
  5. USFDA Certificate
  6. Radiation Safety Certificate From Chinese Government
  7. Test Report From Inspection Center Of State Security Ministry



Patents:

  1. Security equipment image data transmission system(patent no.: 201020700244.8)
  2. One key switch off device for x ray device(patent no.: 201020700256.0)
  3. Sensors device for security inspection(patent no.: 201020700245.2)
  4. Dangerous liquid detecting circuit(patent no.: 201120107219.5)





Multi - Language Handheld X-Ray Baggage Inspection System For Security Check 0
Multi - Language Handheld X-Ray Baggage Inspection System For Security Check 1
