1m Wider Inspection Size Door Frame Metal Detector Gate Big Body Person Security Inspection

small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  1m Wider Inspection Size Door Frame Metal Detector Gate Big Body Person Security Inspection

Product Details:
Place of Origin: CHINA
Brand Name: SECUSCAN
Certification: CE,ISO9001
Model Number: AT300B
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: wooden pallet
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 300 units per month
Detailed Product Description
Feature: Perfect Weather-proofing Design Material: Aluminum Case
Induction Loop: Pure Copper Zones: 6,12, 18 Zones
Alarm: Audio And LED Alarm Warranty: 1 Year
Technical Training: Providing Sensitivity: Detect A Paper Clip
High Light:

metal detector airport


walk through detectors


1m wider inspection size door frame metal detector gate for big body person security inspection


Easy to Install, Simple to Operate


Technical specification:

Electric current: AC100V~240V   50/60Hz
Power: 10W
Work environment: -20°C~+45°C
Gross Weight: 40kg
Outer frame: 2220mm (h) x 820mm (w) X 610mm (d)
Inner frame: 2000mm (h) X 700mm (w) X 610mm (d)



6/12/18 Pinpoint zones to precisely identify multiple target locations from head to toe.
Advanced broadband detection technology: can detect ferrous and Non-ferrous articles.
Sensitivity adjustable from Level 0 o 299
1). High: Can detect a pin
2. Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes.
Shock proof to avoid false alarm
Sound and light alarm
Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.
Tamper-Proof: operate program is protected by password.
Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources
Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity
Harmless to pregnant woman and heart pacemaker.
Two LED light bars on both door panels: gives alarm corresponding to the height or human body.

Superior Versatility: Settings designed for airports, courthouse, Sports meeting, Casino, Electronics factory and Hardware factory.

Networking: Remote ability with Desktop Remote Control. ( Optional )



In accordance with: EN60950, WN50081-1, And EN50082-1
CE Certificate; ISO 9001:2000 Certificate, National standard




 Why will you cooperate with us?


1.  SECU SCAN as the brand of our security equipments and entered into international market since 2008.

2.  And we have entered into the security industry for more than 15 years.

3.  Professional engineer group accept your suggest for customized design.

4.  24 Hours after sales service support

5.  Professional sales reply you with any questions you have in time
