Product Details:
Payment & Shipping Terms:
|
Software Interface: | Support Multi Language | Tube Voltage: | 140kv |
---|---|---|---|
Conveyor Max Load: | 170kg | Training: | Free Of Cost At The Factory |
Installation: | Easy | Operation: | With User Manual |
OEM/ODM: | Accepted | Tunnel Size: | 600(W)*400(H)mm |
Warranty: | One Year Free Spare Parts, Life Time Technic Support | Penetration: | 30-32mm Steel |
High Light: | cargo inspection,baggage x ray machine |
43mm High Penetration Baggage And Parcel Inspection Equipment For Shopping Mall
Our service:
Packing and Shipment:
Packing details |
carton packing |
1 set/ctn |
|
Packing Size: (L)1850*(W)830*(H)1500mm |
|
Gross Weight:500kg |
|
Payment terms |
T/T, Western Union, Cash,L/C |
Shipping methods |
By air (5-7days, most expensive) |
By express (3-7days, more expensive) |
|
By sea (15-28days, cheapest) |
Installation Data:
X Ray Generator:
Beam direction | Upward |
Beam angle | 80 degree |
Anode voltage | 160kv |
Anode power | 0.5mA |
Cooling / Duty Cycle | Oil Cooling /100% |
Specification:
Tunnel Size | 615(W)*418(H)mm |
Conveyor Speed | 0.22m/s |
Conveyor Max Load | 170kg |
Dose per Inspection | <1.4Gy/h |
Resolution | < 0.0787mm Copper Wire |
Spatial Resolution Level | Dia1.0mm |
Vertical | esolution Level: Dia1.0mm Vertical: Dial1.0mm |
Penetrate resolution | 40-43mm |
Film Safety | Guarantee ISO1600 Film |
X-ray Leakage | <0.5 μ Gy/h (at a distance of 5cm From external housing) |
X Ray Image:
X-ray Sensor | L-Shaped Photodiode Array (multi-energetic), 12bit Deep |
Monitor | High Resolution Color, LCD Accord, 17 inch |
Image Processing | Edge enhancement, image strengthening, image lightening, , reducing darkening, image returning, image retrieval. |
Image Grey Level | 4096 |
Image Max Resolution | 1024 * 1280 pixel |
Image Processing | 24bit for processing real time |
Image storage | Storage 60000 pictures in real time |
Zoom | 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation |
Multi-energetic distinguish objects | Organic objects in orange, inorganic objects in blue, mixture in green |
High-energy/low energy | Switch from high energy to low energy |
Adavantage | Assist to detect drug and explosive powder |
Computer Specs:
Applications:
End user | Recommend X Ray Baggage Scanner model NO. |
Airports, Transport terminals | AT6040; AT6550; AT10080; AT100100 |
Factories (to find needle in clothing, shoes, bags), | AT5030; AT6040; AT6550 |
Courthouses, Embassies, Buildings | AT5030; AT6040; AT6550 |
Military installations | AT5030;AT6040; AT6550; AT8065; AT100100 |
Prisons, Hotels, Schools, Convention centers | AT5030; AT6040; AT6550; AT10080 |
Security checkpoints,Special events location | AT5030; AT6040; AT6550; AT8065; AT10080 |
Advantages:
