Product Details:
Place of Origin: China
Brand Name: SECU SCAN
Certification: CE, ISO
Model Number: AT6550
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Pallet
Delivery Time: 1week to 1 month
Payment Terms: TT advance, L/C
Supply Ability: 100pcs/month
Detailed Product Description
Tunnel Size: 650*500mm Penetration: 32mm
Wire Resolution: 40mm Penetration Resolution: 30mm
Generate Angle: 80 Degree Anode Voltage: 100-160kv Adjustable
Anode Power: 0.4-1.2mA
High Light:

x-ray baggage inspection system

,

baggage x ray machine

LCD Accord 650 mm * 500mm Baggage And Parcel Inspection for security control

Model: AT-6550





SECU SCAN X RAY SYSTEM offers a modern technology to secure entry checkpoints for important locations like airports, transport terminals, buildings, and so on. Our systems screen baggage and parcel, to detect contraband, weapons, dangerous and illegal items. Model AT6550 easily accommodates the inspection of small baggage and parcels. SECU SCAN X RAY SYSTEM is based on user-friendly design with ergonomic operator control panel and adjustable control panel stand. It is easy to installation and maintenance. Over 100 systems per month installed in china and abroad. SECU SCAN branded products received certifications of CE, Test report from China Ministry of Public Security and Copyright for image Operation software SPHOTO.


As a manufacturer SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LTD is an ISO 9001:2008, ISO14001:2004   and OHSMS18001 GB/T 28001-2001 (Occupational Health and Safety Management System) certified company. We have Radiation Safety license from China Environmental Protection Administration.


SECU SCAN X RAY SYSTEM is a professional security solution provider, a wise choice to governments and partners.



Specifications:

Tunnel Size:

650(W)*500(H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

150kgs

Dose per Inspection:

<2.9 μGy/h

Resolution:

<0.101mm Metal Wire

Penetration:

34mm Steel

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<0.05 μGy/h (at a distance of 5cm From external housing)

Generate direct:

Upward

Generate angle:

80 degree

Anode Voltage:

100-160Kv

Anode power:

0.4 to 1.2mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic),  12bit Deep

Monitor:

High Resolution Color,  LCD Accord,  17 inch

Image Processing:

Edge enhancement,  image strengthening,  image lightening,

reducing darkening,  image returning,  image retrieval.

Image Grey Level:

4096

Image Max Resolution:

1024 * 1280 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage 60000 pictures in real time

Zones & Zoom:

1-9 Image regions,  2, 4, 8, 16 Times Enlarge,

Whole screen continuous observation

Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

1.1 KW (max),  0.3KW(working)

Noise:

<58db



General Specification:
● Tunnel Size: 650(W)*500(H)mm
● Conveyor Speed: 0.22m/s
● Conveyor Max Load: 170kg
● Dose per Inspection <1.4Gy/h
● Resolution < 0.0787mm Copper Wire
● Spatial resolution Level: dia1.0mm,
Vertical: dia1.0mm
● Penetrate resolution: Dia 0.254mm
● Penetration: 34mm Steel
● Film Safety Guarantee ISO1600 Film
● X-ray Leakage: <0.05 μGy/h (at a distance of 5cm From external housing)

X-ray Generator:

● Generate direct: Upward
● Generate anger: 80 degree
● Anode Voltage: 100~160Kv
●Anode power: 0.4 to 1.2mA
● Cooling / Duty Cycle: Oil Cooling /100%

Image System:
● X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
● Monitor: High Resolution Color, LCD Accord, 17 inch
● Image Processing: Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning, image retrieval.
● Image Grey Level: 4096
● Image Max Resolution: 1024 * 1280 pixel
● Image Processing: 24bit for processing real time
● Image storage: Storage 60000 pictures in real time
● Zones & Zoom: 1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen continuous observation
● Multi-energetic distinguish objects : organic objects in orange, inorganic objects in blue, mixture in green
● High-energy/low energy : switch from high energy to low energy
● Assist to detect drug and explosive powder

Installation Data:
● Operation temperature/Humidity: 0℃-45℃/20%-95%(non-condensing)
● Storage Temperature/Humidity:  -20℃-60℃/20%-95%(non-condensing)
● Operation Power: 220VAC(±10%)50±3Hz
● Power Consumption: 1.0 KW (max), 0.7KW(working)
● Noise: <58db



LCD Accord 650 mm * 500mm Baggage And Parcel Inspection for security control 0LCD Accord 650 mm * 500mm Baggage And Parcel Inspection for security control 1LCD Accord 650 mm * 500mm Baggage And Parcel Inspection for security control 2LCD Accord 650 mm * 500mm Baggage And Parcel Inspection for security control 3LCD Accord 650 mm * 500mm Baggage And Parcel Inspection for security control 4

LCD Accord 650 mm * 500mm Baggage And Parcel Inspection for security control 5
