24 / 33 zones high sensitivity Walk Through Metal Detector for government building security

China SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

24 / 33 zones high sensitivity Walk Through Metal Detector for government building security

24 / 33 zones high sensitivity Walk Through Metal Detector for government building security
24 / 33 zones high sensitivity Walk Through Metal Detector for government building security 24 / 33 zones high sensitivity Walk Through Metal Detector for government building security

Large Image :  24 / 33 zones high sensitivity Walk Through Metal Detector for government building security

Product Details:
Place of Origin: China
Brand Name: SECUPLUS
Certification: ISO CE GB15210-2003
Model Number: SPW300C
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: wooden packing
Delivery Time: 8-10days
Payment Terms: Western Union, T/T, L/C
Supply Ability: 1000units /month
Detailed Product Description
Detection Zones: 8-16-24-33zones Set Freely Sensitiviy Grade: 1-300
Alarm: Sound And Light (alarm Sound Adjustable ) Inner Size: 700-820mm Width Optional
Anti-interference: High Quality Monitor: LCD And Count
Material: Pure Copper Coils Circles
High Light:

walkthrough metal detectors

,

walk through detectors

24 / 33 zones high sensitivity Walk Through Metal Detector for government building security



  •  Multi zone 24 /33 zones programmable in software.
  • Updated DSP technology
  • Simplify PCB. Better for installation and after service
  • Automatically Calibration


Technical Specification

  • Electric current: 80V to 250V
  • Power: 8W
  • Work environment: -20℃~+45℃
  • Gross Weight: 80kg
  • Outer frame: 2220mm (h) x 880mm (w) X 610mm (d)
  • Inner frame: 2000mm (h) X 760mm (w) X 610mm (d)
Net work support
Self-diagnostic procedures
Modular structure easy for after sales service
Automatically adapt to the working environment
Auto scan environmental interference at site
7 inch LCD friendly operation interface for user
Automatically calibration
Operation way: remote control
Two or four LED light bars on both door panels: gives alarm corresponding to the height or human body.
Detect zone: 33/45 zones
Sensitivity adjustable from Level 0 to 300
High: Can detect a coin
Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes.
Shock proof to avoid false alarm
Sound and light alarm
Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.
Tamper-Proof: operate program is protected by password.
Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources.

(Optional)Connect to computer, camera, turnstile,etc; 4 hours embedded battery backup

  • Mix distance between two Walk-thru:0.3 meters at low sensitivity, 0.5meters at high sensitivity
  • Harmless to pregnant woman and heart pacemaker
