Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel

China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel

Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel
Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel

Large Image :  Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel

Product Details:
Place of Origin: China
Brand Name: SECUPLUS
Certification: CE ISO
Model Number: SPX-100100
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden Pallet
Delivery Time: 5-7 working days after payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300sets/moth
Detailed Product Description
Automatic Alarm: Yes Application: Customs, Railway Stations, Military, Express, Postal, Government
Penetration: 38mm Guarantee, 40mm Typical Tunnel Size: 1000*1000mm (Width*Height)
Conveyor Speed: 0.22m/s Max Load: 170kgs
X Ray Generator: 160KV Zoom: Up To X64, Support Continuous Magnification
Storage Capacity: More Than 100000 Image Dual-Direction: Yes
High Light:

baggage scanner machine

,

airport security baggage scanners

Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel

SECUPLUS x ray machine can help reduce false alarm rates, and allow customers to enhance security and potentially drive down operational costs.

SECUPLUS is designed for screening normal checked bagage.It can be widely used in airports, seaports, rail transport stations, critical infrastructures and big events, etc.

High Light:

* Powerful image dealing ability;
* Accurate Z7,Z8,Z9 mark for explosive and narcotics;
* Windows 7 operation system;
* Automatic save scanned image;
* Friendly operation System;
* Reliable performance.

Technical characteristics:

* Duel energy penetration system;
* TIP program;
* Clear and distinct image;
* Scanned imaged can zoom up to 64 times;
* Partly zoom up to 3 times;
* 13 kinds of image processing functions and 6 kinds of pseudo color;


Application field: Train Stations; Metro Station; Jail House ; Embassy; Boarder check points; Entertainment venues; Tourist attractions; Office buildings; Shopping malls; Factories, etc;
*Suitable for security inspection of briefcase, hand luggage, postal parcels and other small packages.

General specs :

Tunnel size 1010mm*1005mm (W*H)
Conveyor speed 0.20m/s
Conveyor height 300mm
Maximum load 200kgs(evenly distributed)
Wire resolution 40AWG(dia 0.0787mm wire)
Spatial resolution Level: dia1.0mm copper wire, Vertical: dia1.0mm copper wire
Penetration(steel) 32mm guarantee, 34mm typical
Penetration resolution 32AWG(0.202mm)
Display 21.5 inch color LCD monitor,high resolution: 1280*1024
X Ray generator anode voltage 160Kv(operating in 150KV)
Cooling cycle Oil Cooling /100%
X ray dose per inspection

<1.0 μSv

X ray generator 1
Beam direction from top to bottom
Image process Black and white / color, anti-color, high energy penetration, super enhancement, histogram equalization, forced scanning, magnifying glass, image pull back / front pull, image storage
Material classification Organic:orange;Inorganic:blue;Mixed and light metal:green
Section and magnification Any area selection,1 -64 times magnification, support continuous amplification
Image pull back unlimited images
Storage capacity Can store at least 100000 pcs image
X ray leakage <0.5 μSv /h(at a distance of 5cm From external housing),meet all international and domestic health and safety standards
Film safety guarantee ASA/ISO1600 Film
Software system F1,F2,F3 programmable key,high density alarm,TIP;date/time display,
baggage Count, User management, System work timing, Radiation timing,
self-inspection while power on, save and search image, automatically
maintenance and diagnosis system, image recognition training.
Optional function Video surveillance system, LED prompt screen, bi-direction scan, voltage
stabilizer, UPS back up
Physical size 3595.5*1285*1795mm (L*W*H)
Weight 1300kgs
Operation temperature/Humidity 0ºC+/-3ºC~+40ºC+/-2ºC 5%~95%(non-condensing)
Storage Temperature/Humidity 40ºC+/-3ºC~+60ºC+/-2ºC 5%~95%(non-condensing)
Operation power 220VAC (+/-10%) 50+/-3HZ
Power consumption 2.0KvA
Noise Less than 55db


Our Services :

1. Operation training program for end users

2. Free of factory training for engineer from agents to end user

3. Provide on-site trainning when customer requires

4. If quality problems happen in guarantee period, our company will maintain for free.

5. One year free spare parts and life time technical support

6. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.

7. If you are caught in some problems when using our products, welcome to contact us at any time.





Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel 0





Detail Images

Operation Keyboard

Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel 1



Our service

  • Operation training program for end users
  • Free of factory training for engineer from agents or end user
  • One year free of spare parts
  • Life time technical support







Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel 2

Airport security x ray scanner Train Boarder With 1000*1000mm Tunnel 3
