160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank

China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank
160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank

Large Image :  160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank

Product Details:
Place of Origin: China
Brand Name: SECUPLUS
Certification: CE ISO
Model Number: spx6550
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden Pallet
Delivery Time: 5-7 working days after payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300sets/moth
Detailed Product Description
Automatic Alarm: Yes Have In Stock: Yes
TIP Program: Support Tunnel Size: 653*505mm (w*h)
Conveyor Speed: 0.20m/s Max Load: 100kgs
X Ray Generator: 160KV Zoom: Up To X64, Support Continuous Magnification
Storage Capacity: More Than 100000 Image Dual-Direction: Yes
High Light:

cargo inspection

,

baggage x ray machine



Dual Energy X Ray Baggage And Parcel Inspection 160kv Generator For Bank Use



High Light

  • Powerful image dealing ability
  • Accurate Z7,Z8,Z9 mark for explosive and narcotics
  • Windows 7 operation system
  • Automatic save scanned image
  • Friendly operation System
  • Reliable performance

Technical characteristics

  • Dural energy penetration system
  • TIP program
  • Clear and distinct image
  • Scanned imaged can zoom up to 64 times
  • Partly zoom up to 3 times
  • 13 kinds of image processing functions and 6 kinds of pseudo color



Application field: Train Stations; Metro Station; Jail House ; Embassy; Boarder check points;
Entertainment venues; Tourist attractions; Office buildings; Shopping malls; Factories, etc;
Suitable for security inspection of briefcase, hand luggage, postal parcels and other small packages.



Technical parameters

Tunnel size 653*505mm (w*h)
Conveyor speed 0.20m/s
Conveyor height 693mm
Max Load 150kgs
Wire Resolution 38AWG
Spatial resolution vertical:diameter 1.0mm,horizontal:diameter 1.0mm
Penetration 35mm steel panel
Monitor 21.5 inch,High resolution 1280*1024
X Ray generator anode voltage 160KV (Working at 150KV)
Cooling/operation cycle Oil Cooling /100%
X ray Dose per inspection < 1.14 USv
Image processing Pseudo color/black & white image,Negative Image, High Penetration, Super-enhancement, histogram equalization, check back/forward, Automatic save image
Zoom Variable zoom up to X64, support continuous magnification.
Image Checking Continuous check back image
Storage capacity Can store more than 100000 image
Radiation leakage <0.5 USv/h(5cm away from fame),in full compliance with all international radiation safety requirements.
Film safety In accordance with ASA/ISO1600 film safe standard
System function F1,F2,F3 programmable key,high density alarm,TIP;date/time display,baggage Count, User management, System work timing, Radiation timing, self-inspection while power on, save and search image, automatically maintenance and diagnosis system, image recognition training.
Optional function Video surveillance system, LED prompt screen, bi-direction scan, voltage stabilizer, UPS back up
Frame size 2043*901*1384mm (L*W*H)
Weight 500kg
Environment temperature/humidity - 3℃~+40℃ / 5%~95%(non-condensing)
Storage temperature/humidity -43℃~+60℃ / 5%~95%(non-condensing)
Power 220VAC (+/-10%) 50+/-3HZ
Consumption 0.7KvA
Noise Level <55db





160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 0



Related Product

Dual Energy X-ray Baggage Scanner SPX5030C

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 1



Detail Images

Operation Keyboard

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 2

Extension Table: 1 set free for customers

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 3



Our service

Operation training program for end users
Free of factory training for engineer from agents or end user
One year free of spare parts
Life time technical support





160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 4

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 5

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 6

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 7

160kv Generator X Ray Baggage Inspection System Dual Energy 55db For Bank 8
