Tunnel Size: | 1010 *1005 Mm | Belt Load: | 200kg |
---|---|---|---|
Belt Speed: | 0.2 M/s | Generator: | 2 Sets |
Computer System: | Windows XP Or 7 | Software: | Multi-language |
Remote: | Remote Workstation | Display: | 17'' Monitor |
Technical Training: | Free | Body Frame: | Stainless Steel |
High Light: | baggage x ray machine,x-ray baggage inspection system |
SPX-100100 is a new type dual-engery dual view X-ray Baggage Scanner and has more efficient image processing technology. It effectively solve the difficulty of reading the image of overlapping items in the luggage. This model helps the security person identifying dangerous goods and contraband more accurately and effectively.
It stands out with more modern and ergonomic design for efficient and professional X-ray screening. It is perfectly suitable for baggage inspection in airports, railway stations, customs,
ports, and stadiums, etc.
High Light:
General specification :
Tunnel size | 1010mm*1005mm (W*H) |
Conveyor speed | 0.20m/s, Bi-direction scan |
Conveyor height | 300mm |
Maximum load | 200kgs(evenly distributed) |
Wire resolution | 40AWG(dia 0.0787mm wire) |
Spatial resolution | Level: dia1.0mm copper wire, Vertical: dia1.0mm copper wire |
Penetration(steel) | 36mm guarantee, 38mm typical |
Penetration resolution | 32AWG(0.202mm) |
Display | 17 inch color LCD monitor,high resolution: 1280*1024 |
X Ray generator anode voltage | 160Kv |
Cooling cycle | Oil Cooling /100% |
X ray generator | 2 units, both 160KV, working in 150KV |
Beam direction | View A : from top to bottom; View B: from Side |
Image process | Black and white / color, anti-color, high energy penetration, super enhancement, histogram equalization, forced scanning, magnifying glass, image pull back / front pull, image storage |
Material classification | Organic; orange;Inorganic:blue;Mixed and light metal:green |
Section and magnification | Any area selection,1 -64 times magnification, support continuous amplification |
Image pull back | Can pull back 50 images |
Storage capacity | Can store at least 100000 pcs image |
X ray leakage | <1μSv /h(at a distance of 5cm From external housing),meet all international and domestic health and safety standards |
Film safety | guarantee ASA/ISO1600 Film |
Software system |
F1,F2,F3 programmable key,high density alarm,TIP;date/time display, baggage Count, User management, System work timing, Radiation timing, self-inspection while power on, save and search image, automatically maintenance and diagnosis system, image recognition training. |
Optional function |
Video surveillance system, LED prompt screen, voltage stabilizer, UPS back up |
Physical size | 3595.5*1685*1795mm (L*W*H) |
Weight | 1480kgs |
Operation temperature/Humidity | -10℃~+45℃; 5%~95%(non-condensing) |
Storage Temperature/Humidity | -20℃~+60℃ 5%~95%(non-condensing) |
Operation power | 110-220VAC , 50/60Hz |
Power consumption | 1 KvA |
Noise | Less than 55db |
Computer | Inter(R) Core (TM) i5-2400 CPU@3.1GHz; Memory(RAM):4GB; Hard disk: 465GB; Windows 7, 64-bit operation system |
