Payment & Shipping Terms:
|Tunnel Size::||600mm×400mm||Conveyor Speed::||0.22m/s|
|Conveyor Height ::||680.5mm||Conveyor Max Load::||160 Kgs|
|Wire Resolution::||38AWG Guarantee, 40AWG Typical||Penetration:||30 Mm Steel Guarantee, 32mm Steel Typical|
airport screening machines,
security screening equipment
Operating Temperature: 0℃-45℃/20%-95%(non-condensing)
Storage Temperature: -20℃-60℃/20%-95%(non-condensing)
Humidity: Up to 95% Non-Condensing
Electrical Health and Safety
Compliant with CE, Center for Devices and Radiation Health Standards for Cabinet X-Ray Systems.
Typical Radiation leakage is less than 0.1 mR/hr(Leakage less than 0.5 mR/hr permitted by the Federal Standard)
Sensitivity: 38 AWG guaranteed, 40AWG typical
Spatial Resolution: 1.0 mm Horizontal, 1.0mm Vertical
Contrast Sensitivity: 24 Visible Levels, 4096 Gray Level
Tube Current: 0.4mA
Cooling: Sealed Di-Electric Oil Bath with Forced Air
Duty Cycle: 100%, No Warm-up Procedure Required
Beam Direction: Diagonally Upward
Detector: L-Shaped Photodiode Array (multi-energetic) ,
1) Multi-energetic x-ray scanner,color scanning image
2) Standard penetration in 32mm steel, resolution 38AWG
3) High density objects automatic alarming by sounds and LED
4) Assist check suspicious explosive and narcotics objects by distinguish the organic and inorganic objects.
5) One year warranty and lifetime technic support
Processor: Intel Celeron 2.6GHz 1333 MHz
Memory: 2 GB RAM at 800 MHz
Storage: 500 GB
Video Card: 256 MB Video Card, Dual Digital Display
Platform: Windows XP
Display Type: Single 17’’ LCD Color Monitor
Display Resolution: 1280 X 1024; 24 bit/pixel Color
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
|Lead time||5-7 days after received the payment|
|Warranty||12 months after shipment|
|Technic support||online by whatsapp,skype or email (Lifetime support)|
Contact Person: Suey
