Wide Vision Water Proof Under Vehicle Surveillance System One Year Warranty

Large Image : Wide Vision Water Proof Under Vehicle Surveillance System One Year Warranty

Product Details:

Place of Origin:	China
Brand Name:	V-SCAN
Certification:	CE,ISO
Model Number:	AT3300

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Wooden case
Payment Terms:	Western Union, L/C, T/T
Supply Ability:	300 units/month

Contact Now

Detailed Product Description

Resolution:	5000*2048 Pixels	Size:	1200*350mm(for Embedding Part)
Memory:	2G(optional 4G)	CPU:	Intel Core(TM) 2 Duo CPU
Monitor:	22 Inch LCD, Resolution Up To 1920*1080	Warranty:	One Year
Operating Temperature:	-10℃to +55℃	Input:	2 Channels Induction Coil
Water-proof:	IP68	Camera:	Line Scan CCD
Highlight:	under vehicle monintor machine , car surveillance system

Wide Vision Water Proof Under Vehicle Surveillance System One Year Warranty

Features of UVSS:

Auto digital line scan, high-resolution undercarriage imaging.
High automation, easy to be used.
Applicable to variety of vehicles, wide vision.
Test will be completed during the vehicle maneuvers without stopping, adapted to different speed.
Undercarriage image can be stored, retrieved, searched or compared with other images.
A variety of image processing methods: enlarge, stretching and cutting.
Multi entrance management model, management, and statistics of entering and exiting vehicles.
Flexible detection process can be made on site to satisfy the needs of various work conditions.
Option of automatic number plate recognition system available, associative storage of various vehicle information and undercarriage images.
Image monitoring, video recording for different scenario.
Suitable for all vehicles, wide vision

Advantages:

Special air-drying circulation system for anti-fog function.
Use digital line scanning technology, can get compelte and high resolution images of the chassis of the vehicle.
Black&white image verison and color image version for customer choice.
Water-proof design, can be used in the rain.
Can connect 4 line DVR, get videos of the on-site from different directions, front, back, side
With the software, can identify the license plate and display on the screen
Can automatically compare the last undercarriage image and the current image of the same vehicle with the same license plate no.
Support one monitor to control 2 or 4 units under vehicle scanenrs at different entries .
Can connect with the barrier system.
Support the network access

Main Technical Data:

Embedded Under Vehicle Imaging Equipment:

Camera Sensor	line scans CCD
Resolution	5000*2048 pixels
Power Supply	24VDC, 3A
Illumination	LED
Power Supply	24VDC, 150W
Size	1200mm x 350mm
Operating Temperature Range	-10 degree to +55 degree

Controller:

Input	2 channel induction coil (can optional extend to 3 channel)
Output	1 channel switch type 12VDC
Communicatoin port	RS422, RS232, Ethernet (Optional)
Operating Temperature Range	-10 degree to +55 degree

System host:

CPU	Intel Centurion Duo or higher
Memory	2G
Hard Disk	500G
Dual LAN	At least one Intel Gigabit
Display	22” LCD, can choose a vice display to show the image independently (optional)
Scene Video Record	4 channel, Compression algorithm of scene video: H264

Our service:

Professional reply for your question in time before-sales during Monday to Friday in 24 hours
All of our product already get passing the aging test to ensure reliability quality
Quality inspection department will check the machine again before packing.
One year spare parts in free for replacing the broken after delivery
Remote control the machine for diagnosing
Technic support by video and telephone
Accept your engineer come to our factory for training in free
Send engineer to your country with additional cost.
