Outdoor Walk Through Security Scanners With French And English Software Interface

Outdoor Walk Through Security Scanners With French And English Software Interface

Technical specification

• Electric current: AC100V~230V 50/60Hz
• Power: 10W
• Work environment: -20~+45
• Gross Weight: 95kg
• Outer frame: 2220mm (h) x 820mm (w) X 610mm (d)
• Inner frame: 2000mm (h) X 700mm (w) X 610mm (d)

Characteristic:

• 6,12,18 Pinpoint zones to precisely identify multiple target locations from head to toe.
• Advanced broadband detection technology: can detect ferrous and non-ferrous articles.
• Sensitivity adjustable from Level 0 to 299 (300 levels) ,
• High: Can detect a pin,
• Low: Detect big metal articles such as: knife, gun, and copper, aluminums,zinc (more than 150g), ignoring metal in belt button, shoes.
• Shock proof to avoid false alarm
• Sound and light alarm

• Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.
• Four LED light bars on both door panels: gives alarm corresponding to the height or human body.
• Tamper-Proof: operate program is protected by password.
• Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources
• Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity
• Harmless to pregnant woman and heart pacemaker.
• With Remote controller
• LCD screen show operate steps in English and Chinese
• Superior Versatility: Settings designed for airports, courthouse, Sports meeting, Casino, Electronics factory and Hardware factory.
• Networking: Remote ability with Desktop Remote Control ( Optional )

Standards:

In accordance with: EN60950, WN50081-1, EN50082-1

CE Certificate; ISO 9001:2000 Certificate / National standard

Our Services

1. Professional reply for your question in time before-sales during Monday to Friday in 24 hours
2. All of our product already get passing the aging test to ensure reliability quality
3. Quality inspection department will check the machine again before packing.
4. One year spare parts in free for replacing the broken after delivery
5. Remote control the machine for diagnosing
6. Technic support by video and telephone
7. Accept your engineer come to our factory for training in free
8. Send engineer to your country with additional cost.

Wooden pallet packign for safe shipment :
