Portable Car Security Checking Under Vehicle Inspection System Digital Camera in Kenya

Portable Car Security Checking Under Vehicle Inspection System Digital Camera in Kenya

   Model: SPV-3000 UVSS, UVIS

 Under Vehicle Inspection System mainly adopt to inspect the beneath part of a variety of vehicles.

It can quickly and accurately identify threats/ contraband/ smuggling of persons hiding at the bottom.

Technical parameters:

•  Vertical resolution of the image: 5000*2048 pixels
•  Check the width viewing angle: not less than 4 meters

•  Speed of vehicle: < 30km/h with ALPR (Automatic License Plate Recognition)
                < 70km/h without ALPR (Automatic License Plate Recognition)
•  Effective field of view( FOV): less than 170°
•  FOV inspecting width: < 4 meters
•  Auxiliary light: 100W
•  Weight capacity: 30T
•  Water-proof grade: IP68
•  Scanning device weight: <24KG
•  Scanning device volume: 450mm×400mm×88mm
•  Communication interface: RS232/RS422
•  Operating Temperature: -20℃ to 55℃
•  Storage temperature: -20℃ to +75℃
•  Operating voltage: 110-240V AC, 50-60HZ

Computer :

●  Brand: Grantech (UFO6377H-SP1-953)

●  CPU: Intel® Core(TM) 2 Duo CPU P8600@2.4GHz or higher

●  Memory:2G( optional 4G)

●  Graphics: Inter(R) Gen 5.0 Integrated Graphics Engine

●  Hard Disk: SATA2 Hard Disk 500G

●  Dual LAN (At least one Intel Gigabit)

●  USB2.0 (Up to 4 pieces)

●  Monitor: 21.5 inch LCD, resolution up to 1920*1080

Optional :

ALPR(Automatic License Plate Recognition)

Under vehicle inspection workshop
