Advanced Integrated Under Vehicle Surveillance System With ANPR

China SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

Advanced Integrated Under Vehicle Surveillance System With ANPR

Advanced Integrated Under Vehicle Surveillance System With ANPR
Advanced Integrated Under Vehicle Surveillance System With ANPR Advanced Integrated Under Vehicle Surveillance System With ANPR Advanced Integrated Under Vehicle Surveillance System With ANPR Advanced Integrated Under Vehicle Surveillance System With ANPR

Large Image :  Advanced Integrated Under Vehicle Surveillance System With ANPR

Product Details:
Place of Origin: China
Brand Name: VSCAN
Certification: CE, ISO9001, ISO18001
Model Number: AT3300
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Box
Payment Terms: Western Union, L/C, T/T
Supply Ability: 100 sets per month
Detailed Product Description
Software Interface: English, Russia, French Function: To Check Weapons On Vehicles
Technology: CCD Line Scan Technology Enterprise: Manufacturer
Camera: Color Alert: For Suspicious Articles
Display: 21 Inch Monitor Technical Traning: Providng
Installation: Engineer Support Onsite Warranty: 1 Year
High Light:

under vehicle inspection systems

,

car surveillance system

Advanced Integrated Under Vehicle Surveillance System With ANPR

  •  Vehicle security control at the entrance
  •  To see whats hidden under the vehicle


Features:



Auto digital line scan, high-resolution undercarriage imaging.



High automation, easy to be used.



Applicable to variety of vehicles, wide vision.



Test will be completed during the vehicle maneuvers without stopping, adapted to different speed.



Undercarriage image can be stored, retrieved, searched or compared with other images.



A variety of image processing methods: enlarge, stretching and cutting.



Multi entrance management model, management, and statistics of entering and exiting vehicles.



Flexible detection process can be made on site to satisfy the needs of various work conditions.



Option of automatic number plate recognition system available, associative storage of various vehicle

information and undercarriage images.



Image monitoring, video recording for different scenario.


-------------------------------------------------------------------------------------------------------------
Technical Specification:



Camera CCD Line scan camera
Resolution 5000* 2048 pixels
Pixels size 14μm*14μm
linear array 28mm
ADC Resolution 12 bit
Image Black/white (color optional)
Power Supply 24VDC
Transfer interface/distance Gigabit Ethernet/100m
LED Illumination Power Supply 24VDC, 150W
Embedded scanning part size 1200mm x 350mm
 Water-proof grade IP68
Operating Temperature -20 ℃ to +70 ℃


Computer :


Brand Grantech (SYM76941 VGGA)
CPU Intel (R) Celeron (R) CPU E3400, 2.6GHz /2.59GHz
Memory 2G (optional 4G)
Graphics 512M
ard Disk SATA2 Hard Disk 500G
USB 2.0 (Up to 2 pieces)
 Monitor 21.5” LCD, resolution up to 1920*1080
Scene Video Record 4 channels
Compression algorithm of scene video  H264
Operational system Windows XP, Windows 7 (32 bit)



Our Services



  1.  Free training in our factory
  2. Technic support by telepone or video
  3. Accept arrange engineer to your country with additonal cost
  4. After-sales service online 18/24 hours
  5. Remote control the machine for maintenance diagnosing
  6. Free spare parts supply during the warranty
  7. Exclusive agent protection and special support for market
  8. OEM  and ODM service accept
our after-sales service team as below:

Advanced Integrated Under Vehicle Surveillance System With ANPR 0

ompany Information



The biggest manufacturer of threats detecting device in south of China.
With professional R&D engineer team are specialized in:
  •  Under vehicle inspection system(HOT)
  •  X-ray screening system for baggage (HOT)
  •  X-ray container/vehicle scanner(New&cCustomized)
  •  Walk through metal detectors
  •  Hand held metal detector
  •  Explosive and Drug trace detection
  •  Dangerous liquid scanner
Workshop of UVSS:
Advanced Integrated Under Vehicle Surveillance System With ANPR 1
