Inorganic X Ray Scanning Machine / Security Screening Machine

Inorganic X Ray Scanning Machine / Security Screening Machine
Inorganic X Ray Scanning Machine / Security Screening Machine Inorganic X Ray Scanning Machine / Security Screening Machine Inorganic X Ray Scanning Machine / Security Screening Machine Inorganic X Ray Scanning Machine / Security Screening Machine

Large Image :  Inorganic X Ray Scanning Machine / Security Screening Machine

Product Details:
Place of Origin: China,Shenzhen
Brand Name: SECUSCAN
Certification: CE,ISO
Model Number: AT5030C
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: Plywood packages
Payment Terms: Western Union, T/T, L/C
Detailed Product Description
Scanning Color: Orange,blue,green,black Baggage Size For Scanning: 500mm(W)*300mm(H)
Tube Current: 50/60Hz Tube Power: 140Kv
Machine Color: White Or Blue Warranty: One Year After Delivery
Support: Technic Online By Video Or Email
High Light:

security screening equipment

,

airport baggage scanner



Inorganic X Ray Scanning Machine / Security Screening Machine





Applicatioin:



Public place security control like hotel,bank,school,embassy,jail,border,building,airport,train station,etc



Parcel and baggage inspection in logistic or express company in warehouse.



Technic specifications:



  •  Tunnel Size: 503mm*303mm Capable of screening object size of 490mm(W)*290(H)mm without corner cut off
  •  Dimensions: 1662mm(L)*726mm(W)*1205mm(H)
  •  Net Weight: 450 kgs
  •  Flow of conveyor belt: Bidirectional(Forward and Reverse)
  •  Conveyor Speed: 0.22m/s
  •  Conveyor Height: 740mm from Floor
  •  Conveyor Capacity: 150 kgs
  •  Construction: Custom Steel Frame/Panels



Technical

  •  Sensitivity: 38 AWG guaranteed, 40AWG typical
  •  Spatial Resolution: 1.0 mm Horizontal, 1.0mm Vertical
  •  Contrast Sensitivity: 24 Visible Levels, 4096 Gray Level



X-Ray Generator

  •  Voltage: 140KV
  •  Tube Current: 0.4mA
  •  Cooling: Sealed Di-Electric Oil Bath with Forced Air
  •  Duty Cycle: 100%, No Warm-up Procedure Required
  •  Beam Direction: Diagonally Upward
  •  Detector: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep

Computer

  •  Processor: Intel Celeron 2.6GHz 1333 MHz
  •  Memory: 2 GB RAM at 800 MHz
  •  Storage: 500 GB
  •  Video Card: 256 MB Video Card, Dual Digital Display
  •  Platform: Windows XP
  •  Backup: Uninterrupted Power Supply (20min)



Video

  •  Display Type: Single 17’’ LCD Color Monitor
  •  Display Resolution: 1280 X 1024; 24 bit/pixel Color



Environmental

  •  Operating Temperature: 0℃-45℃/20%-95%(non-condensing)
  •  Storage Temperature: -20℃-60℃/20%-95%(non-condensing)
  •  Humidity: Up to 95% Non-Condensing



Electrical

Health and Safety

  •  Compliant with CE, Center for Devices and Radiation Health Standards for Cabinet X-Ray Systems.
  •  Typical Radiation leakage is less than 0.1 mR/hr(Leakage less than 0.5 mR/hr permitted by the Federal Standard)
