Product Details:
Payment & Shipping Terms:
|
| Tunnel Size: | 1000*1000 Mm | Density Objects: | Alarm To Remind The Operator |
|---|---|---|---|
| Hard Disk: | 500 GB Or More | Image: | Color |
| Software: | Multi-language And Friendly | Special Function: | To Detect Explosives |
| Technology Training: | Providing | Image Storage: | 100000 Pcs |
| UPS: | To Supply Power When Electricity Cut Down | Output Roller: | To Avoid Objects Fall Down |
| High Light: | security screening equipment,airport baggage scanner |
||
Duel Energy X Ray Baggage Scanner , Xray Scanner Airport
Technology Features:
1. Multi-Energy penetration system
2. New x-ray protection technology
3. Multi-functions image processing system
4. EI-TIP( Threat Image Projection) function
5. Shiny clear images
6. Any selection of the image magnified area
7. Collect the high-speed parallel of detection data
8. Movable machine with integrated structure
9. Sophisticated design with multi-functions operator interface
10. Support JPG&BMP image transformation format to USB
Specifications:
|
Tunnel Size: |
1000(W)*1000(H)mm |
|
Conveyor Speed: |
0.22m/s |
|
Conveyor Max Load: |
200kgs |
|
Dose per Inspection: |
<2.9 μGy/h |
|
Resolution: |
<0.101mm Metal Wire |
|
Penetration: |
38mm Steel |
|
Film Safety: |
Guarantee ISO1600 Film |
|
X-ray Leakage: |
<0.05 μGy/h (at a distance of 5cm From external housing) |
|
Generate direct: |
downward |
|
Generate angle: |
80 degree |
|
Anode Voltage: |
160Kv |
|
Anode power: |
0.4 to 0.5mA |
|
Cooling / Duty Cycle: |
Oil Cooling /100% |
|
X-ray Sensor: |
L-Shaped Photodiode Array (mono-energetic), 12bit Deep |
|
Monitor: |
High Resolution Color, LCD Accord, double 17 inch |
|
Image Processing: |
Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval. |
|
Image Grey Level: |
4096/65536 |
|
Image Max Resolution: |
1024 * 1280 pixel |
|
Image Processing: |
24bit for processing real time |
|
Image storage: |
Storage 100,000 pictures in real time |
|
Zones & Zoom: |
1-9 Image regions, 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation |
|
Operation temperature/Humidity: |
0℃-45℃/10%-95%(non-condensing) |
|
Storage Temperature/Humidity: |
-20℃-60℃/10%-95%(non-condensing) |
|
Operation Power: |
187~240VAC, 50/60Hz |
|
Power Consumption: |
1.0 KW |
|
Noise: |
<58db |
Competitive Advantage:
* Integrated, cost Effective, Turn-Key Security
* Fit for small Baggage and Parcel Security Inspection.
* Increased detection capability
* Friendly interface for ease-of-use
* Reliable performance and uncompromising value
Secuscan services :
* Operation training program for end users
* Free of factory training for engineer from agents or end user
* One year free of spare parts
* Life time technical support
