22 inch LCD Monitor Under Vehicle Surveillance System for under truck inspection

22 inch LCD Monitor Under Vehicle Surveillance System for under truck inspection
22 inch LCD Monitor Under Vehicle Surveillance System for under truck inspection 22 inch LCD Monitor Under Vehicle Surveillance System for under truck inspection

Large Image :  22 inch LCD Monitor Under Vehicle Surveillance System for under truck inspection

Product Details:
Place of Origin: China
Brand Name: VSCAN
Certification: CE,ISO
Model Number: AT-3300
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden case
Supply Ability: 300 unts/month
Detailed Product Description
CPU: Intel Centurion Duo Or Higher Memory: 2G(optional 4G)
Graphics: 512M Hard Disk: SATA2 Hard Disk 500G
Dual LAN: At Least One Intel Gigabit Monitor: 22 Inch LCD, Resolution Up To 1920*1080
High Light:

under vehicle inspection systems

,

car surveillance system

22 inch LCD Monitor Under Vehicle Surveillance System for under truck inspection

Model: AT-3300



Features of UVIS:
1. Auto digital line scan, high-resolution undercarriage imaging.
2. High automation, easy to be used.
3. Applicable to variety of vehicles, wide vision.
4. Test will be completed during the vehicle maneuvers without stopping, adapted to different speed.
5. Undercarriage image can be stored, retrieved, searched or compared with other images.
6. A variety of image processing methods: enlarge, stretching and cutting.
7. Multi entrance management model, management, and statistics of entering and exiting vehicles.
8. Flexible detection process can be made on site to satisfy the needs of various work conditions.
9. Option of automatic number plate recognition system available, associative storage of various vehicle information and undercarriage images.
10. Image monitoring, video recording for different scenario.

Advantage of UVSS:
No need to park vehicle, can bear speed below 30km/h
Whole image display ion monitor
Operator can zoom and save image

Main Technical Indexes:

Embedded Under Vehicle Imaging Equipment

1. Camera: Sensor: line scans CCD, Resolution: 2048, Power Supply: 24VDC, 5A
2. Illumination: LED, Power Supply: 24VDC, 150W
3. Size: 1200mm x 350mm
4. Operating Temperature Range: -40 degree to +70 degree

Controller
1. Input: 2 channel induction coil (can optional extend to 3 channel)
2. Output: 1 channel switch type 12VDC
3. Communication Port: RS422, RS232, Ethernet (Optional)
4. Operating Temperature Range: -10 degree to +55 degree

System Host
1. CPU: Intel Centurion Duo or higher, Memory: 2G, Hard Disk: 500G
2. Display: 22” LCD, can choose a vice display to show the image independently (optional)
3. Scene Video Record: 4 channel, Compression algorithm of scene video: H264
