Metal Detector Gates with audio and visual alarm for foreign objects

Metal Detector Gates with audio and visual alarm for foreign objects

Model No.: AT-IIIC

High sensitivity, economic model
Suit for Factories and Entertainment environments

Technical specification :

* Electric current: AC100V~240V 50/60Hz
* Power: 10W
* Work environment: -20º C~+45º C
* Gross Weight: 70kg
* Outer frame: 2220mm (h) x 820mm (w) X 522mm (d)
* Inner frame: 2000mm (h) X 700mm (w) X 522mm (d)

Characteristic:

* 6 Pinpoint zones to precisely identify multiple target locations from     head to toe.
* Advanced broadband detection technology: Can detect ferrous and    non-ferrous articles.

* Sensitivity adjustable from Level 0 to 299
  High: Can detect a pin
  Low: Detect big metal articles such as: Knife, gun, and copper,    aluminums, zinc (more than 150g), ignoring  metal in belt button, shoes.

* Shock proof to avoid false alarm
* Sound and light alarm
* Intelligent traffic and alarm counters that calculate traffic flow
  And resultant alarms.
* Two LED light bars on both door panels: Gives alarm
  Corresponding to the height or human body.

* Tamper-Proof: Operate program is protected by password.
* Adjustable operating frequencies---eliminate the potential effects From X-ray units, radios and other    electrical interference sources
* Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity
* Harmless to pregnant woman and heart pacemaker.
* Remote control unit ( Optional )

Standards:

* In accordance with: EN60950, WN50081-1, EN50082-1
* CE Certificate; ISO 9001: 2000 Certificate, National standard
* National standard

Function: Walkthrough Metal Detector can easily detect weapons, such as knife and gun, and any metal article which is hidden in human body.
