Product Details:
Payment & Shipping Terms:
|
| Material: | Stainless Steel | Function: | To Check Contraband In Bags |
|---|---|---|---|
| Scanning Image: | Color, B/W | Technical Traning: | Free |
| Software Interface: | English, Spanish, French, Russia | Computer System: | Windows XP |
| Remote Station: | Yes | Network: | LAN, Ethernet |
| High Light: | Baggage checking,baggage x ray scanner |
||
India AERB certificate approved x-ray machine luggage scan for night club, hotels to check bomb, drug in suitcase
Model: AT6550
India Atomic Energy Regulatory Board and Film Safety Approved from India Government.
----------------------------------------------------------------------------------------------------------
With a 650 mm wide by 500 mm high tunnel opening, the Secuscan AT6550 provides outstanding threat detection and a low total cost of ownership.
The AT6550's innovative design allows for bi-directional operation, while ergonomic options such as its adjustable control panel stand make it easy to operate.
----------------------------------------------------------------------------------------------------------
Advantages:
* Proven Checkpoint Screening Performance
* Automatic Detection of Explosives and Narcotics
* Ergonomic Design
* Network Enabled
* Performance and Value
----------------------------------------------------------------------------------------------------------
General Specification:
| Tunnel Size | 650(W)*500(H)mm |
| Conveyor Speed: | 0.22m/s |
| Resolution | < 0.0787mm Copper Wire |
| Penetration: | 34mm Steel |
| Film Safety | Guarantee ISO1600 Film |
| X-ray Leakage: | <0.1 μ Gy/h (at a distance of 5cm From external housing) |
----------------------------------------------------------------------------------------------------------
X-ray Generator:
* Generate direct: Upward
* Generate anger: 80 degree
* Anode Voltage: 100~160Kv
* Anode power: 0.4 to 1.2mA
* Cooling / Duty Cycle: Oil Cooling /100%
----------------------------------------------------------------------------------------------------------
Image System:
* X-ray Sensor: L-Shaped Photodiode Array (multi-energetic), 16 bit Deep
* Monitor: High Resolution Color, LCD Accord, 17 inch
* Image Grey Level: 65536
* Image Max Resolution: 1024 * 1280 pixel
* Image Processing: 24bit for processing real time
* Image storage: Storage 100, 000 pictures in real time
* Zoom: 32 Times Enlarge, Whole screen continuous observation
* Multi-energetic distinguish objects: Organic objects in orange, inorganic objects in blue, mixture in green
* Assist to detect drug and explosive powder
----------------------------------------------------------------------------------------------------------
Installation Data:
Operation temperature/Humidity: 0º C-45º C/20%-95%(non-condensing)
Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
Operation Power: 220VAC(± 10%)50± 3Hz
Power Consumption: 0.7KW(working)
Noise: <58dB
----------------------------------------------------------------------------------------------------------
