X Ray Scanning Machine For Museum

TSA approved x-ray bag scanning/screening device/machine to inspect luggages in museum, government agency, shopping mall

Model: AT6040

----------------------------------------------------------------------------------------------------------
      With a 600 mm wide by 400 mm high tunnel opening, the Secuscan AT6040 provides outstanding threat detection and a low total cost of ownership.

    The AT6040's innovative design allows for bi-directional operation, while ergonomic options such as its adjustable control panel stand make it easy to operate.

----------------------------------------------------------------------------------------------------------
Advantages:

* Proven Checkpoint Screening Performance
* Automatic Detection of Explosives and Narcotics
* Ergonomic Design
* Network Enabled
* Performance and Value

----------------------------------------------------------------------------------------------------------
General Specification:

* Tunnel Size: 600(W)*400(H)mm
* Conveyor Speed: 0.22m/s
* Conveyor Max Load: 170kg
* Resolution < 0.0787mm Copper Wire
* Penetration: 34mm Steel
* Film Safety Guarantee ISO1600 Film
* X-ray Leakage: <0.1 μ Gy/h (at a distance of 5cm From external housing)

----------------------------------------------------------------------------------------------------------
X-ray Generator:

* Generate direct: Upward
* Generate anger: 80 degree
* Anode Voltage: 100~160Kv
* Anode power: 0.4 to 1.2mA
* Cooling / Duty Cycle: Oil Cooling /100%

----------------------------------------------------------------------------------------------------------
Image System:

* X-ray Sensor: L-Shaped Photodiode Array (multi-energetic), 16 bit Deep
* Monitor: High Resolution Color, LCD Accord, 17 inch
* Image Grey Level: 65536
* Image Max Resolution: 1024 * 1280 pixel
* Image Processing: 24bit for processing real time
* Image storage: Storage 100, 000 pictures in real time
* Zoom: 32 Times Enlarge, Whole screen continuous observation
* Multi-energetic distinguish objects: Organic objects in orange, inorganic objects in blue, mixture in green
* Assist to detect drug and explosive powder

----------------------------------------------------------------------------------------------------------
Installation Data:

Operation temperature/Humidity: 0º C-45º C/20%-95%(non-condensing)
Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
Operation Power: 220VAC(± 10%)50± 3Hz
Power Consumption: 0.7KW(working)
Noise: <58dB

----------------------------------------------------------------------------------------------------------
Any interest, just send me email.

Secuscan engineer team :
