100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection

China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection

100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection
100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection

Large Image :  100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection

Product Details:
Place of Origin: China
Brand Name: SECU PLUS
Certification: CE ISO
Model Number: SPX-5030C
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywood Pallet
Delivery Time: 7 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 sets/ month
Detailed Product Description
Tunnel Size: 504*320mm (w*h) Penetration: 14-16mm Steel Panel
X Ray Generator Anode Voltage: 100KV Wire Resolution: 38AWG
Monitor: 17inch,resolution 1280*1024 Name: X Ray Baggage Scanner
High Light:

38AWG X Ray Baggage Scanner

,

100KV X Ray Baggage Scanner

,

38AWG Baggage Scanner Machine

 100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection

High Light

  • 100kv multi energy scanner
  • Professional multi-function operation keyboard;
  • Automatic save scanned image;
  • ​Friendly Image processing interface
  • Windows 7 operation system;
  • With independent industrial computer;

Technical characteristics


  • New radiation protection technology
  • TIP program
  • Scanned imaged can zoom up to 32 times
  • Integrated structure design, refinement appearance
  • Clear and distinct image


Baisc specification:

X Ray Generator:



X Ray generator anode voltage 100KV
Cooling/operation cycle Oil Cooling /100%
X ray Dose per inspection <0.16 μSv




Tunnel size 504*320mm (w*h)
Conveyor speed 0.20m/s
Conveyor height 693mm
Max Load 100kgs
Wire Resolution 38AWG
Spatial resolution vertical:diameter 1.0mm,horizontal:diameter 1.0mm
Penetration 14-16mm steel panel




X Ray Image:



Image processing Pseudo color/black & white image,Negative Image, High Penetration, Super-enhancement, histogram equalization, check back/forward, Automatic save image
Zoom Variable zoom up to X32, support continuous magnification.
Image Checking Continuous check back image
Storage capacity Can store more than 100000 image
Dose per inspection <0.125 μSv
Radiation leakage <0.4 μSv/h(5cm away from fame),in full compliance with all international radiation safety requirements.
Film safety In accordance with ASA/ISO1600 film safe standard
System function F programmable key,high density alarm,TIP;date/time display,baggage Count, User management, System work timing, Radiation timing, self-inspection while power on, save and search image, automatically maintenance and diagnosis system, image recognition training.
Optional function Video surveillance system, LED prompt screen, voltage stabilizer, UPS back up



Installation environment:



Frame size 1199*728*1197mm (L*W*H)
Weight 280kg
Environment temperature/humidity - 3℃~+40℃±2℃ / 5%~95%(non-condensing)
Storage temperature/humidity -43℃~+60℃±2℃ / 5%~95%(non-condensing)
Power 220VAC (+/-10%) 50+/-3HZ
Consumption 0.6KvA
Noise Level <55db



Application field



  • Entertainment venues, tourist attractions, office buildings, shopping malls, factories, etc;
  • suitable for security inspection of briefcase, hand luggage, postal parcels and other small package.



Detailed image:


100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection 0
100KV 38AWG X Ray Baggage Scanner Machine Small Parcel Inspection 1
