Product Details:
Payment & Shipping Terms:
|
Tunnel Size: | 600mm(W)*400mm(H) | Penetration: | 34mm Guarantee, 38mm Typical |
---|---|---|---|
Conveyor Height: | 680mm | Conveyor Load: | 170kgs |
Conveyor Speed: | 0.22m/s | Language: | Support Multi Language |
Name: | Baggage X Ray Machine | Approx Weight: | 700KG |
Highlight: | Multi Language Baggage X Ray Machine,Embassy Baggage X Ray Machine,Multi Language x ray baggage machine |
Embassy Use Multi Language Baggage X Ray Machine For Hotel
Installation Data:
Operation temperature/Humidity: | 0℃-45℃/20%-95%(non-condensing) |
Storage Temperature/Humidity: | -20℃-60℃/20%-95%(non-condensing) |
Operation Power: | 220VAC(±10%)50±3Hz |
Power Consumption: | 1.5KW (max), 0.3KW(working) |
Noise: | <58db |
Physical Specifications:
Dimensions: Length: | 2,190 mm Width: 878mm Height: 1,280mm |
Tunnel Size: | 600mm(W) x 400mm(H) |
Conveyor Speed: | 0.22m/s |
Approx Weight: | 700KG |
System Power: | 220 VAC ±10% /50Hz |
Steel Penetration: | 34mm guaranteed; 38mm typical |
Wire Resolution: | 38AWG guaranteed; 40 AWG typical |
Image System:
Monitor: |
High Resolution Color, LCD Accord, 21.5 inch |
Image Processing: |
Edge enhancement, image strengthening, image lightening, |
Image Grey Level: |
4096 |
Image Max Resolution: |
1024 * 1280 pixel |
Image Processing: |
24bit for processing real time |
Image storage: |
Storage 60000 pictures in real time |
Zones & Zoom: |
1-9 Image regions, 2, 4, 8, 16 Times Enlarge, |
