Multi - Zones Walk Through Metal Detector Gate

Multi-zones Walk Through Metal Detector Gate ; Factories(to find needle in clothing, shoes, bags

Specifications:

Electric current: AC100V~240V   50/60Hz

Power: 10W

Work environment: -20℃~+45℃

Gross Weight: 70kg

Outer frame: 2220mm (h) x 820mm (w) X 522mm (d)

Inner frame: 2000mm (h) X 700mm (w) X 522mm (d)

General specification:

* 6 Pinpoint zones to precisely identify multiple target locations from head to toe.
* Advanced broadband detection technology: can detect ferrous and non-ferrous articles.
* Sensitivity adjustable from Level 0 to 299

   High: Can detect a pin
   Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes.
* Shock proof to avoid false alarm
* Sound and light alarm
* 2 LED light bars on both door panels:gives alarm corresponding to the height or human body.
* Tamper-Proof: operate program is protected by password.
* Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources.
* Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity
* Harmless to pregnant woman and heart pacemaker


Applications:

Commercial buildings; Factories(to find needle in clothing,  shoes,  bags)
Courthouses; Embassies; Government buildings;
Military installations; Prisons; Hotels;
Schools; Convention centers; Security checkpoints.

Excellent system for schools,  hotels,  convention centers and event-based security requirements
