| Tunnel size |
504*320mm (w*h) |
| Conveyor speed |
0.20m/s |
| Conveyor height |
693mm |
| Max Load |
100kgs |
| Wire Resolution |
38AWG |
| Spatial resolution |
Vertical: diameter 1.0mm, horizontal: diameter 1.0mm |
| Penetration |
10mm steel panel |
| Monitor |
17inch, resolution 1280*1024 |
| X Ray generator anode voltage |
80KV |
| Cooling/operation cycle |
Oil Cooling /100% |
| X ray Dose per inspection |
<0.16 μSv |
| Image processing |
Pseudo color/black & white image, Negative Image, High Penetration, Super-enhancement, histogram equalization, check back/forward, Automatic save image |
| Zoom |
Variable zoom up to X64, support continuous magnification. |
| Image Checking |
Continuous check back image |
| Storage capacity |
Can store more than 100000 images |
| Radiation leakage |
<0.4 μSv/h(5cm away from fame), in full compliance with all international radiation safety requirements. |
| Film safety |
In accordance with ASA/ISO1600 film safe standard |
| System function |
F programmable key, high density alarm, TIP; Date/Time display, Baggage Count, User management, System work timing, Radiation timing, Self-inspection while power on, Save and search image, Automatically maintenance and diagnosis system, Image recognition training. |
| Optional function |
Video surveillance system, LED prompt screen, Bi-direction scan, Voltage stabilizer, UPS back up |
| Frame size |
1199*728*1197mm (L*W*H) |
| Weight |
280kg |
| Environment temperature/humidity |
- 3℃～+40℃±2℃ / 5%～95%(non-condensing) |
| Storage temperature/humidity |
-43℃～+60℃±2℃ / 5%～95%(non-condensing) |
| Power |
220VAC (+/-10%) 50+/-3HZ |
| Consumption |
0.6KvA |
| Noise Level |
<55db |
