Product Details:
Payment & Shipping Terms:
|
| Vehicle Magnetic Sensor: | 4pcs | Ground Sensor: | 1pc |
|---|---|---|---|
| Wind Resonance Sensor: | 1pc | Detection Time: | 15-60s (adjustment) |
| Software: | Multi-language Support | Alarm: | Audio And Visual |
| Warranty: | 18 Months | Technical Training: | Free |
| High Light: | 240VAC Under Car Security Scanner,Human Presence Under Car Security Scanner,Heatbeat Movement Car Surveillance System |
||
Microseismic Human Presence & Intrusion Detection in border to detect stowaway in customs, border
Multi - Language Security Human Presence Heatbeat movement detection system
Secuplus SPV-2018CL is a-one-of-a-kind security inspection system that detects human beings by sensing the vibrations caused by the human heartbeat hiding in vehicles or containers that are loaded on vehicles.
The technology is more reliable and cost-effective than other sensor approaches, and safer and faster than manual searches.
General specification :
| Power Supply | 110VAC-240V / 50/60 Hz |
| Operating temperature | -20°C to 60°C |
| Relative humidity | 10 to 90% non-condensing |
| Max. wind speed | 35 km/h ( worlds best performance !) |
| Max. natural vibrations | 0.4m/s |
| Dimensions | 98cm(L)*63cm(W)*130cm(H) |
| Weight | 65kgs |
| Steering System | 360° |
| Detection time | 15-60s (adjustment) |
| Mounting way | horizontal |
| IP grade | Dust rating: IP6X; Waterproof rating: IPX8 |
|
Sensors
|
Vehicle Magnetic sensor - 4 pcs Ground sensor - 1 pc Wind resonance sensor - 1 pc |
| Computer |
Processor: Intel Quad-Core, 2GHz industrial grade, RAM: DDRII 8GB System memory: 1G or better for option Hard disk: 500GB; Interface: USB2.0 Serials port: D-sub9 needles; Parallel port: D-sub25 needle Ethernet interface: 10M/100M RJ45; |
|
Software
|
Windows 7 |
.
Our Services:
2. Accept arrange engineer to your country with additonal cost
3. After-sales service online 18/24 hours
4. Remote control the machine for maintenance diagnosing
5. Free spare parts supply during the warranty
6. Exclusive agent protection and special support for market
7. OEM and ODM service accept
