UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot

UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot
UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot

Large Image :  UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot

Product Details:
Place of Origin: China
Brand Name: SECUPLUS
Certification: ISO CE
Model Number: SPV-3300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywood pallet
Delivery Time: within 5working days after reeving your payment
Payment Terms: T/T, Western Union, L/C
Supply Ability: 500 sets per month
Contact Now
Detailed Product Description
Input: 2 Channels Induction Coil Output: 1 Channel Switch Type 12VDC
Camera: Sensor: Line Scans CCD Resolution: 5000*2048 Pixels
Have In Stock: Yes Illumination: LED
Size: 1200mm X 350mm Vehicle Speed: 1-60Km/h, Suggest ≤1-30km/h
Scanning Mode: Linear Scan, Ground Coil Trigger Water-proof Grade: IP68
Highlight:

under vehicle monintor machine

,

car surveillance system

UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot



Under vehicle surveillance system mainly adopt to inspect the beneath part of a variety of vehicles.

It can quickly and accurately identify threats/ contraband/ smuggling of persons hiding at the bottom. UVSS greatly improved vehicle safety inspection speed and accuracy, reduce investment in human resources.



Highlight:



Special air-drying circulation system
With intelligent alarm
Weather proof scanning unit(IP 68)
Anti-fog function
To connect anti-collision system, barrier,etc,
To compatibly packing management solution



Features:

  1. Multi entrance management model, management, and statistics of entering and exiting vehicles
  2. Auto digital line scan, high-resolution undercarriage imaging.
  3. High automation, easy to be used
  4. Applicable to variety of vehicles, wide vision.
  5. Test will be completed during the vehicle maneuvers
  6. without stopping, adapted to different speed.
  7. Undercarriage image can be stored, retrieved, searched or compared with other images.
  8. Avariety of image processing methods: enlarge, stretching and cutting.
  9. (Optional)ALPR-Automatic License Plate Recognition and RFID technology. associative storage of various
  10. Vehicle information and undercarriage images.

UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 0

Embedded Screening Part:



Camera Sensor: line scans CCD
Resolution 5000*2048 pixels
Power Supply 24VDC, 3A
Illumination LED
Power Supply 24VDC,150W
Size 1200mm x 350mm
Operating Temperature Range -20 degree to +70 degree



Controller:



● Input: 2 channels induction coil
● Output: 1 Channel switch type 12VDC
● Communication port: RS485, Ethernet(Optional)
● Operating Temperature: -10℃ to 55℃



System Host:



Brand Grantech (SYM76941VGGA)
CPU Intel(R)Celeron(R)CPU
Memory 2G( optional 4G)
E3400@2.6GHz 2.59 GHz
Graphics 512M
Dual LAN (At least one Intel Gigabit)
USB2.0 (Up to 2 pieces)
Monitor 22 inch LCD, resolution up to 1920*1080
Hard Disk SATA2 Hard Disk 500G
Scene Video Record: 4 channel, Compression algorithm of scene video: H264



UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 1

Related product: Hand Held Under Vehicle Search Camera



UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 2

Work shop: in huge stocks



UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 3

UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 4



Security Electronic Equipment Co., Ltd



Our company established since 2008, and specialized in security equipments about 10 years.
Main products:
  • X ray baggage scanner
  • Small Vehicle X-ray Scanner
  • Walk through metal detector
  • Hand Held Metal Detector
  • Under vehicle surveillance system
  • Explosives/drug detector
  • Dangerous Liquid scanner etc.
The best offer will be provided after receving your inquiry.

​Small size X-ray Baggage Scanner SPX5030A/C
UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 5



Walk Through Metal detector



UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 6

UVSS Under Vehicle Detection Equipment Inspection System Waterproof IP68 SPV-3300 for parking lot 7
