Tunnel Size: | 504 * 320 Mm | Belt Load: | 100kg |
---|---|---|---|
Belt Speed: | 0.2 M/s | Image: | Color |
Computer System: | Windows 7 | Software: | Multi-language Support |
Remote: | Remote Workstation | Display: | 17'' Monitor |
Storage: | 500GB | Multi-energy: | Identify Organic And Non-organic Objects |
Highlight: | airport screening machines,security screening equipment |
Technical data:
Tunnel size | 504*320mm (w*h) |
Conveyor speed | 0.20m/s |
Conveyor height | 693mm |
Max Load | 100kgs |
Wire Resolution | 38AWG |
Spatial resolution | vertical:diameter 1.0mm,horizontal:diameter 1.0mm |
Penetration | 10mm steel panel |
Monitor | 17inch,resolution 1280*1024 |
X Ray generator anode voltage | 100KV |
Cooling/operation cycle | Oil Cooling /100% |
X ray Dose per inspection | <0.16 μSv |
Image processing | Pseudo color/black & white image,Negative Image, High Penetration, Super-enhancement, histogram equalization, check back/forward, Automatic save image |
Zoom | Variable zoom up to 32X, support continuous magnification. |
Image Checking | Continuous check back image |
Storage capacity | Can store more than 100,000 image |
Radiation leakage | <0.4 μSv/h(5cm away from fame),in full compliance with all international radiation safety requirements. |
Film safety | In accordance with ASA/ISO1600 film safe standard |
System function | F programmable key,high density alarm,TIP;date/time display,baggage Count,User management, System work timing, Radiation timing, self-inspection while power on, save and search image, automatically maintenance and diagnosis system, image recognition training. |
Optional function | Video surveillance system, LED prompt screen, bi-direction scan, voltage stabilizer, UPS back up |
Frame size | 1199*728*1197mm (L*W*H) |
Weight | 280kg |
Environment temperature/humidity | - 3℃~+40℃±2℃ / 5%~95%(non-condensing) |
Storage temperature/humidity | -43℃~+60℃±2℃ / 5%~95%(non-condensing) |
Power | 220VAC (+/-10%) 50+/-3HZ |
Consumption | 0.6KvA |
Noise Level | <55db |
