Product Details:
Payment & Shipping Terms:
|
Huge Stocks: | Yes | Display Resolution: | 800*480(RGB) |
---|---|---|---|
Camera: | Infrared Miniature Wide-angle HD Camera | Have In Stock: | Yes |
Start-up Time: | ≤1.0s | Continuous Working Time: | No Less Than 12 Hours |
Total Weight: | 3.4Kg | Maximum Opening Angle: | 180 Degrees |
High Light: | Hand Held Under Vehicle Search Camera,Airport Security Under Vehicle Search Camera,12.6V Under Vehicle Surveillance Camera |
Hand Held Under Vehicle Search Camera SPV918 easy operate for Airport security
SPV918 Under Vehicle Search Camera is mainly used to check the bottom of the vehicle, determine whether
vehicle to hide suspicious explosives or dangerous, personnel, whether the overall structure of the bottom of the
vehicle is illegal change, also can be used for the bottom of the table, bed, file cabinets, security check high
platform, pipeline, pipeline, shaft, internal box inside, among the trees and other human inconvenience the
arrival position
Description:
Function | The camera can rotate left, right, rotate and stop automatically |
Angle | The maximum horizontal angle is 355 degrees, The minimum horizontal angle is 22.5 degrees |
Focal distance | 3.6mm |
Focal length | Wide-angle |
Definition | 600 line and 1/3SONYCCD infrared image sensor, high definition with infrared night vision function |
Power supply | SCM dedicated power charging and discharging technology to ensure the reliability of power supply products |
Working environment temperature | -20℃ to +60℃ |
Working current | 400mA |
Monitor |
7 inch Color |
Display resolution | 800*480(RGB) |
Specifications:
Power |
6800mW
|
Start-up time | ≤1.0s |
Total Weight | 3.4Kg |
Spreading length | 1780mm |
Folding length | 1020mm |
Volume | 1020*180*280mm |
Packing | 1050*210*310mm |
Battery capacity | 5200Ah |
Working voltage | 9-12.6V |
Continuous working time | no less than 12 hours |
Features
Micro wide-angle high definition camera, with infrared night vision ability, wider vision, clearer
Excellent design concepts based on this system, using two folding structure, the maximum opening angle of 180 degrees, can be pushed into the 1800mm deep caves and can visit, electric control camera angle, the body is made of high strength Aluminum Alloy stamping molding, high temperature paint, beautiful light. The operation is extremely labor-saving
The package is made of ergonomically designed bags. It is light and easy to carry. It can be used both by hand and shoulder
Detail Images
Application place:
Related products: Under Vehicle Inspection System SPV3300:
