Product Details:
Payment & Shipping Terms:
|
| Outer Frame: | 2220mm (h) X 820mm (w) X 522mm (d) | Inner Frame: | 2000mm (h) X 700mm (w) X 522mm (d) |
|---|---|---|---|
| Gross Weight: | 89kg | Have In Stock: | More Than 50 Units |
| Sensitivity: | 0 To 300 Adjustable | Warranty: | 1 Year |
| Zones: | 6/12/18 Optional | Alarm Counter: | Yes |
| High Light: | metal detectors at airports,door frame metal detector |
||
18 zones Walk Through Metal Detector Gate SPW-IIIC Gun Detector
Description:
1 Keyboard and remote control
2 Extremely high sensitivity to find even tiny threats
Characteristic
1. Shock proof to avoid false alarm
2. Advanced broadband detection technology: Can detect ferrous and non-ferrous articles.
3. Sensitivity adjustable from Level 0 to99
High: Can detect a clip
Low: D e t e c t b i g m e t a l a r t i c l e s s u c h a s: K n i f e, gun, and copper, aluminums, zinc
(more than 150g), ignoring metal in belt button, shoes.
4.6 Pinpoint zones to precisely identify multiple target locations from head to toe.
5. Sound and light alarm
6. Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.
7. Tamper-Proof: Operate program is protected by password.
8. Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources.
9. Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity
10. Harmless to pregnant woman and heart pacemaker
11. Remote control (Optional)
12. Connect with computer, camera, turnstile, etc (Optional)
Technical specification
| Electric current: | AC215V~230V 50/60Hz |
| Power: | 35W |
| Work environment : | -20degree~+45degree |
| Gross Weight: | 95kg |
| Outer frame: | 2220mm (h) x 820mm (w) X 522mm (d) |
| Inner frame: | 2000mm (h) X 700mm (w) X 522mm (d) |
1. Operation training program for end users
2. Free of factory training for engineer from agents to end user
3. Provide on-site trainning when customer requires
4. If quality problems happen in guarantee period, our company will maintain for free.
5. One year free spare parts and life time technical support
6. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
7. If you are caught in some problems when using our products, welcome to contact us at any time.
| X ray Baggage Scanner | SPX4233/SPX5030C/SPX6040/SPX6550/SPX8065/SPX10080/SPX100100/SPX150180 |
| X-ray Vehicle Scanner | SPV-200RF/SPV-160FD |
| Under Vehicle Surveillance System | SPV3300/SPV3000/SPV918/SPV915/SPV916/SPV910 |
| Hand Held Metal Detector | MD3003B1/ SPM-2008/SPM-2009/V160/ |
| Liquid Scanner | SP1500/SP1000/SP1800 |
| Explosives Detector | SPE3000/SPE7000/SPE9000 |
| Tunnel size | 1010mm*1005mm (W*H) |
| Conveyor speed | 0.20m/s |
| Conveyor height | 300mm |
| Maximum load | 200kgs(evenly distributed) |
| Wire resolution | 40AWG(dia 0.0787mm wire) |
| Spatial resolution | Level: dia1.0mm copper wire, Vertical: dia1.0mm copper wire |
| Penetration(steel) | 32mm guarantee, 34mm typical |
| Penetration resolution | 32AWG(0.202mm) |
| Display | 21.5 inch color LCD monitor,high resolution: 1280*1024 |
| X Ray generator anode voltage | 160Kv(operating in 150KV) |
