Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner

China Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner supplier
Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner supplier Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner supplier Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner supplier Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner supplier

Large Image :  Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner

Product Details:

Place of Origin: China
Brand Name: SECU PLUS
Certification: CE,ISO
Model Number: SPV-5000ES

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Wooden case
Delivery Time: 14 days
Supply Ability: 300 unts/month
Contact Now
Detailed Product Description
Sensor: Area Scan Coil: 2 Channels Indouction Coil
Scanning Resolution: 4096P Speed Of Vehicle: 1-60km/h
Auxiliary Lighting: 100W Warranty: One Year

Waterproof Area Scan Under Vehicle Surveillance System , Under Car Scanner



Advantages of UVSS:

  • Area scanning technology, the scanning image more real
  • Complete and clear image display on monitor
  • Automatic comparison the latest scanning image with the most similar historical image and mark the difference
  • Operator can zoom, recall,  save and inquire image
  • Driver face image capture



Main Technical Indexes:



Technology: ultra-high frame rate integrated smart area array scanning technology
Scanning resolution: 4096P
Undercarriage storage or loading time: <1 second
Vehicle image display mode large-format horizontal display
Chassis image storage format standard BMP image format or JPEG
The system interface language optional, Chinese, English, Russian, Arabic
Display resolution adapt to kinds of display resolution, maximum 1366 * 768
Vehicle image data transmission interface network RJ45
Scene image display ≥ 1 road (up to 4 roads can be reached)
The bottom of the car image resolution 10000 × 4096
Image function Auto image shooting,Automatic image storage, delete function, Image quality adjustment function
Operating Temperature: -10℃ to +75℃
Storage temperature: -40℃ to +75℃
Operating voltage: 110-240V AC, 50-60HZ


System Host



Display

15.5 inch true color LCD display

CPU INTEL i5-3230 Core Quad-Core Processor
Motherboard

dedicated motherboard

Memory DDR3, 4GB
Graphics DDR3, 192BIT independent graphics card
Hard Disk 500G high-speed hard disk
Working voltage

AC220V 50/60Hz

Working current 3A
Working temperature -20 °C ~ 60 °C



Scanning unit and control equipment specification:



Scanning mode area array scanning, ground coil detection, infrared trigger
The maximum scan rate 18kHz
Detection speed 1-60km / h, recommended ≤ 30km / h
Field of view angle

≥ 170 degrees

Scanner data line 10 meters; (customizable length)
Auxiliary lighting 100W
Lighting components

10 sealed LED surface light source; life: 50000h

Carrying weight more than 40T
Waterproof rating IP68 to meet all-weather work
Scanning device weight

30KG

Scanning device size 753 * 353 * 41mm
Structural design single seal design, high-intensity compression design, with dust, moisture, rain
Communication interface

RJ45

Working voltage

DC24V

System power supply AC110-240V/50-60Hz
Leakage current 0.1mA



Company introduction:



The manufacturer of threats detecting device in south of China.
With professional R&D engineer team are specialized in:
  • X-ray screening system for baggage
  • Walk through metal detectors
  • Hand held metal detector
  • Under vehicle inspection system
  • Explosive and Drug trace detection
  • Dangerous liquid scanner
  • X ray vehicle scanner
We have successful cases in airports,customs and government, important events for protection.
The reliable military supplier of security screening system..


Our service:

  • Professional reply for your question in time before-sales during Monday to Friday in 24 hours
  • All of our product already get passing the aging test to ensure reliability quality
  • Quality inspection department will check the machine again before packing.
  • One year spare parts in free for replacing the broken after delivery
  • Remote control the machine for diagnosing
  • Technic support by video and telephone
  • Accept your engineer come to our factory for training in free
  • Send engineer to your country with additional cost.



Workshop picture:



Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner



Waterproof Under Vehicle Surveillance System , 100W Auxiliary Lighting Under Car Scanner
