100W UVIS Under Vehicle Surveillance System AT3000 Effective View Field 170°

China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

100W UVIS Under Vehicle Surveillance System AT3000 Effective View Field 170°

100W UVIS Under Vehicle Surveillance System AT3000 Effective View Field 170°
100W UVIS Under Vehicle Surveillance System AT3000 Effective View Field 170°

Large Image :  100W UVIS Under Vehicle Surveillance System AT3000 Effective View Field 170°

Product Details:
Place of Origin: China
Brand Name: V-SCAN
Certification: ISO CE
Model Number: AY3000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywoof Pallet
Delivery Time: within 10 working days
Payment Terms: L/C, Western Union, T/T
Supply Ability: 500 sets per month
Detailed Product Description
Vertical Resolution Of The Image: 5000*2048 Pixels Effective Field Of View(FOV): Less Than 170°
Auxiliary Light: 100W Weight Capacity: <20T
Scanning Device Weight: 24KG Memory: 2G( Optional 4G)
High Light:

under vehicle inspection systems

,

car surveillance system

Under Vehicle System Manufacture AT3000 Portable Vehicle Scanner

Features:

  1.  Automatic digital line scan camera, with high-resolution and clarity of the image.
  2.  The complete image of under vehicle scanning, without any omissions,
  3.  and the image is clear, complete, no distortion, can be clearly observed that
  4.  the object is not less than 2mm in diameter.
  5.  Preparation of inspection processes to meet a variety of on-site needs.
  6.  Multiple scene image monitoring, recording function.
  7.  Multi-language user interface design.
  8.  Strong scalability to easily achieve a variety of system linkage control.
  9.  (Optional)ALPR(Automatic Licence Plate Recognition)
  10.  Optional Multiple devices networked control functions

System Host:

  • Brand: Grantech (UFO6377H-SP1-953)
  • CPU: Intel® Core(TM) 2 Duo CPU P8600@2.4GHz or higher
  • Memory:2G( optional 4G)
  • Graphics:Inter(R) Gen 5.0 Integrated Graphics Engine
  • Hard Disk:SATA2 Hard Disk 500G
  • Dual LAN (At least one Intel Gigabit)
  • USB2.0 (Up to 4 pieces)
  • Monitor: 22inch LCD, resolution up to 1920*1080

Technical parameters:

Vertical resolution of the image 5000*2048 pixels
Check the width viewing angle < 4 meters
Speed of vehicle

< 30km/h with ALPR(Automatic Licence Plate Recognition)
< 70km/h without ALPR(Automatic Licence Plate Recognition)

Effective Field of View(FOV) less than 170°
Auxiliary light 100W
Weight capacity <20T
  1. Water-proof grade-------- Ip68
  2. Scanning device weight---------------24KG
  3. Scanning device volume---------------450mm×400mm×88mm
  4. Communication interface---------------RS232/RS422
  5. Operating Temperature------------ -10℃ to 55℃
  6. Storage temperature------------------- -40℃ to +75℃
  7. Operating voltage------------------ 110-240V AC, 50-60HZ

Color Scan Image:
100W UVIS Under Vehicle Surveillance System AT3000 Effective View Field 170° 0
