Product Details:
Payment & Shipping Terms:
|
| Frame Material: | Stainless Steel | Images Storage: | 100,000 Image |
|---|---|---|---|
| Software Interface: | English, French, Russia, Spainish | Alarm: | Sound And Light Alarm |
| Warranty: | 2 Years | Converyor Load: | 200kg |
| Software: | English, Russian, French, Spainsh | Display: | 17" Monitor |
| Technical Support: | Life Time | Image: | B/W, Color |
| High Light: | security screening equipment,airport baggage scanner |
||
FDA approved security x ray scanning system in high speed rail station
| Tunnel Size: | 1000(W)*1000(H)mm |
| Conveyor Speed: | 0.22m/s |
| Conveyor Max Load: | 200kg |
| Wire Resolution: | 38AWG |
| Penetration: | 32 mm Steel |
| Film Safety: | Guarantee ISO1600 Film |
| X-ray Leakage: | <1 μSv/h (at a distance of 5cm from external housing) |
Installation Data:
|
Operation temperature/Humidity: |
0℃-45℃/20%-95%(non-condensing) |
| Storage Temperature/Humidity: | -20℃-60℃/20%-95%(non-condensing) |
| Operation Power: | 187~240VAC, 50/60Hz |
| Power Consumption: | 1.0 KW (max), 0.3KW(working) |
| Noise: | <65db |
X-ray Generator
| Beam direction: Diagonal | Diagonal |
|
Generate angle: |
80 degree |
| Anode Voltage: | 160Kv |
| Anode power: | 0.4 to 0.5mA |
| Cooling / Duty Cycle: | Oil Cooling /100% |
Image System
| X-ray Sensor: | L-Shaped Photodiode Array (multi-energetic) , 12bit Deep |
| Monitor: | High Resolution Color, LCD Accord, 17 inch (19 inch optional) |
| Image Processing: |
Edge enhancement, image strengthening, image lightening, reducing darkening, image returning,image retrieval. |
| Image Grey Level: | 4096 |
| Image Processing: | 24bit for processing real time |
| Image storage: | Storage 60000 pictures in real time |
| Zoom: | max 16 Times Enlarge, Whole screen continuous observation |
Application:
Special for hotel and Metro baggage inspection
Functions:
Top Scanning ability
Stable and reliable: each machine had strict high and low temperature test, high humidity test, anti-shock test,
MTBF 10000 hours
Automatic sensor roller (Optional)
Upgrade quality solution (Optional)
Shipping way: delivery by sea, air, DHL
Packaging: plywood package, one unit in one package, packing size: 182*89*145cm gross weight: 450KG
1. One-to-one exclusive service
2. Online diagnosis service for after-sales service
3. 12-24 months warranty for providing free spare parts
4. Free training in factory for your engineer
5. Accept arranging engineer go abroad for trainning should be paid
6. Tender protection with authorization certificate
