Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel

China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel

Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel
Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel

Large Image :  Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel

Product Details:
Place of Origin: China
Brand Name: SECUSCAN
Certification: FDA, CE, ISO
Model Number: AT6550B
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywood package: Size: 217*102*158cm Gross weight: 660kgs
Payment Terms: Western Union, T/T, L/C
Supply Ability: 500+set+per month
Detailed Product Description
Tunnel Size:: 650mm×500mm Conveyor Speed:: 0.22m/s
Conveyor Height :: 670mm Conveyor Max Load:: 160 Kgs
Wire Resolution:: 38AWG Guarantee, 40AWG Typical Penetration: 38 Mm Steel Guarantee, 40mm Steel Typical
High Light:

airport screening machines

,

airport baggage scanner



Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel


Product Description

High penetration 38mm steel Baggage x-ray inspection system

Model:
Specifications
AT5030
Color Scanning image, small size for parcel screening
AT6040
Middle size for baggage inspection, high resolution scanning image
AT6550
Middle size with independent console, hotel using popular model
AT10080
Big size for luggage inspecting, popular for express/Logistic company using.
AT100100
Big size for luggage scanning in color image, automatic alarming for high density objects



The SECU SCAN AT6550B is designed for screening small objects as well as baggage and large parcels for hotel, government, aviation, customs application.
Greatest Number of Operator-Assist Tolls Enables Highest Throughput
With Over 12 image processing tools, the feature rich software helps the operator easily and accurately detect contraband for the highest throughput and least operator fatigue



Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel 0
Standard Features

Multi Energy Imaging(4 Color)
Scanner entrance and exit protective cover added
View Previous/Next Bag
Manual Image Archive
Multi-function keyboard
Emergency stop button
Baggage Counter
Date/Time Display
Search Indicator
UPS(Uninterrupted Power Supply)-Optional
Independent Workstation
22’’ LCD Monitor
Extension roller-Optional

Standard Image Processing Functions

Crystal Clear
Black and White
Organic / Inorganic Stripping
Inverse image
High penetration
Low penetration
Variable Edge Enhancement
Variable Color Stripping


Specification

Standard X-Ray Generator and Image Performance
Tunnel size: 650mm(W)*500mm(H)
Steel Penetration: 38mm guaranteed; 40mm typical
Wire Resolution: 38 AWG guaranteed; 40 AWG typical
Generator Cooling: Sealed oil bath with forced air
Anode Voltage: Operating at 160kV (SPELLMAN from US)
Tube Current: 0. 7 mA
Orientation: Upward
X-ray beam angle: 80 degree (complete image of maximum size of baggage displayed without corner cuts)


Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel 1

Detailed Images


Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel 2Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel 3Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel 4


Packing & Delivery
One unit packing in two plywood boxes



Scanner packing size: 237*111*163cm
Scanner gross weight: 600kgs
Console packing size: 88*88*143cm
Console gross weight: 70kgs

Airport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel 5
Our Company



As the biggest manufacture of security x-ray inspection system in south of China since 2003.
Welcome join SECUSCAN and cooperate with us for supplying baggage scanner, walk through metal detector, under vehicle surveillance system, explosive detector and liquid scanner.etcAirport security X Ray Baggage Scanner for detecting weapons , high penetration 38mm steel 6
