50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition

China 50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition supplier
50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition supplier 50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition supplier 50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition supplier 50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition supplier

Large Image :  50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition

Product Details:

Place of Origin: China
Brand Name: VSCAN
Certification: CE
Model Number: AT3300

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 1~ 8888 per set
Packaging Details: plywood packages
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 set per months
Contact Now
Detailed Product Description
Weather Proof Level: IP68 View Angle: 170 Degree
Auxiliary Light: 80W ,LED Scanning Image: Complete Whole Image
Screen: 22inch LCD

Passing speed 50km/hour under vehicle inspection machine AT3300







Technic specification of UVSS:



System host:

Brand: Grantech (UFO6377H-SP1-953)

CPU: Intel® Core(TM) 2 Duo CPU

P8600@2.4GHz or higher

Memory:2G( optional 4G)

Graphics:Inter(R) Gen 5.0 Integrated Graphics Engine

Hard Disk:SATA2 Hard Disk 500G

Dual LAN (At least one Intel Gigabit)

USB2.0 (Up to 4 pieces)

Monitor: 22inch LCD, resolution up to 1920*1080

Scene Video Record: 4 channel, Compression algorithm of scene video: H264





Embedded screening parts:

Camera: Sensor: line scan CCD

Resolution: 5000*2048 pixels

Power Supply: 24VDC, 3A

Illumination: LED, Power Supply: 24VDC,150W

Size: 1200mm x 350mm

-25 degree to +70 degree



50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition

Controller:

Input: 2 channels induction coil

Output: 1 Channel switch type 12VDC

Communication port: RS485, Ethernet(Optional)

Operating Temperature: -10℃ to 55℃

50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition



Company profile:



SEE(Security Electronic Equipment Co., Limited) have nearly twenty thousand square meters of production base to produce x-ray baggage 300 sets of x-ray baggage scanner, 500 sets of liquid scanner, 1000 sets of walk through metal detector per month. SEE developed a series of quality standards higher than international standards, we use the core components of well-known brands and supporting devices from outsourcing to produce and assemble by our professional workers. Each device have passed vibration, heat and radiation leak testing and a series of reliability testing. SEE have a strict national standards before leaving the factory.



50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition50km/Hour Under Vehicle Surveillance System For Security Checking , High Definition



Wide range of products for your market we produced:

Description Model NO. Application
X-ray baggage Scanner AT5030/AT6040/AT6550/AT8065/AT10080/AT100100 Airport,custom,Hotel
Walk Through Metal Detector AT-IIIA,AT-IIIC, AT-IIID,AT300A,AT300B,AT300C,AT300S Border,exhibition,government
Bottle Liquid Scanner AT1000, AT1800, AT1500 Metro,station
Under Vehicle Surveillance System AT3300, AT3000 Prision, Jail
Explosive Trace Detector HD300, HD600 Military base
