Home ProductsX Ray Baggage Scanner

Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station

Good quality Baggage And Parcel Inspection for sales
Good quality Baggage And Parcel Inspection for sales
I'm Online Chat Now

Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station

China Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station supplier
Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station supplier Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station supplier Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station supplier

Large Image :  Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station

Product Details:

Place of Origin: China
Brand Name: SECUPLUS
Certification: CE ISO FCC ROHS
Model Number: SPX8065

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD1-15000set
Packaging Details: wooden packing
Delivery Time: within 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 sets per month
Contact Now
Detailed Product Description
Tunnel Size: 800(W)*650(H)mm OEM: Accept
Conveyor Speed: 0.22m/s Conveyor Max Load: 200kg
Have In Stock: Yes Anode Voltage: 140Kv

Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station



General Specification :


Tunnel Size: 800mm×650mm
Conveyor Speed: 0.22m/s
Conveyor height : 338.5mm
Conveyor Max Load:200kg
X ray Dose per inspection <0.1.25μSv
Wire Resolution:38AWG Guarantee 40 AWG typical
Spatial resolution Level: dia1.3mm,Vertical: dia1.3mm
Penetration: 30 mm steel guarantee, 32mm steel typical
Penetration Resolution :30AWG guarantee, 32AWG typical
Film Safety :Guarantee ASA/ISO1600 Film
X-ray Leakage: <0.5 μSv/h (at a distance of 5cm From external housing)


Image System :


Technical Principle: Dual-energy X-ray Imaging;
X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
Monitor: High Resolution Color, LCD Accord, 17inch
Image Display: High resolution of 1024 * 1280 pixel; Image Grey Level: 65536
Image Enhancement: 1-64times enlargement continuity, Color/BW, negative, high/low penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc.
Image Recall: All preceding images recallable, retrieval.
Explosives & Narcotics Detection: Explosives & narcotics alarm and highlight according to atomic number
signature
High Density Region Alarm: Impenetrable region alarm and highlight, for possible concealing of threats and contrabands
Threat Image Projection: Inserting fictional, but realistic images of threat items into baggage during screening operation, for maintenance of vigilance, as well as training and assessment of image identification capability
Image Archive: Up to 100,000 images stored automatically, enable transferring to USB disk, and converting to JPG, BMP and other general formats
Miscellaneous Functions : Time/date display, counters, user management, system-on/X-ray-on timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log,
system standby and stimulant training, ADS etc.
Network Applications: Multiple remote applications available based on Ethernet LAN and windows platform, such as image centralized storage and identify, recheck workstation, and network TIP, etc ( Optional) .
Images process: 24bit real time processing ,4colors analysis, Images displayed marked date and
ID NO ,Count the number of bags.

Memory gray level: 65536



X-ray Sensor L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
Monitor High Resolution Color, LCD Accord, 17 or 19inch
Image Grey Level 4096
Image Max Resolution 1024 * 1280 pixel
Image Processing 24bit for processing real time


Operating Environment:


Operation temperature/Humidity:5℃-40℃/10%-95%(non-condensing)
Storage Temperature/Humidity: -20℃to 60℃/ 5%-95%(non-condensing)
Operation Power: 220VAC(±10%)50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
Power Consumption: 1.0KW (max), 0.7KW(working)
Noise: <58db
Dimensions (L×W×H): 2848.5mm x1095mm x1535.5 mm
Device Weight: 680Kg
G.Weight: 900Kg
Packing Volume: 6.63CBM



Computer Character:


CASE: IPC7132
Power: 250W/ATX
Main board: AIMB 501G2
CPU: G1610 2.6G
Storage: 2GB 1600MHz DDR3 Innodisk
Hard Disk: SEAGATE 500G 3.5”



X-ray Generator:



Anode Voltage: 140kv
Anode power: 0.3mA
Generate angle: 80 degree upward
Brand: own made
Generate direct: from top to bottom
Cooling / Duty Cycle: Oil Cooling /100%



Other Characters:



Detect PCB board: UK brand Sensortech
Extension Rollers: customize size length
Support card reader operator access
CD DVR/RW unit: Optional
Computer system: XP system
Monitor: 17 inch DELL two monitors





Our Work Shop



Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station

Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for Station
