Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive

China Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive supplier
Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive supplier Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive supplier Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive supplier Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive supplier

Large Image :  Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive

Product Details:

Place of Origin: China
Brand Name: SECUSCAN
Certification: CE, ISO9001, AERB, US.FDA
Model Number: AT5030C

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: 1000~20000 USD PER UNIT
Packaging Details: Wooden Box
Delivery Time: One week
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 sets/month
Contact Now
Detailed Product Description
Body Material: Stainless Steel Tunnel Size: 500*300mm
Conveyor Load: 150kg Software: Multi-language
TIP: Threat Image Protection ADS: To Detect Explosive, Drug
Warranty: 12 Months Display: 17 Inch LCD

Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive



General Specification:



Tunnel Size: 500mm×300mm
Conveyor Speed: 0.22m/s
Conveyor height : 670mm
Conveyor Max Load: 150kg
X ray Dose per inspection <0.5uGy
Wire Resolution: 38AWG Guarantee 40 AWG typical
Spatial resolution Level: dia1.0mm,Vertical: dia1.0mm
Penetration: 32 mm steel
Penetration Resolution : 32AWG ,the wire visible below 22mm thick aluminum
Film Safety : Guarantee ASA/ISO1600 Film
X-ray Leakage: <0.5 μGVy/h (at a distance of 5cm From external housing)



Image System:



Technical Principle: Dual-energy X-ray Imaging; Double L Shaped Array,576 detectors
Image Enhancement: 1-64times enlargement continuity, Color/BW, negative, high/low
penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc.
Image Display: High resolution of 1280×1024
Image Recall: All preceding images recallable
Explosives & Narcotics Detection: Explosives & narcotics alarm and highlight according to atomic
number signature
High Density Region Alarm: Impenetrable region alarm and highlight, for possible concealing of threats and contrabands
Threat Image Projection: Inserting fictional, but realistic images of threat items into
baggage during screening operation, for maintenance of vigilance, as well as training and assessment of image identification capability
Image Archive: Up to 100,000 images stored automatically, enable transferring to USB disk, and converting to JPG, BMP,PNG and other general formats
Miscellaneous Functions : Time/date display, counters, user management, system-on/X-ray-on
timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and stimulant training,self-diagnostic etc.
Network Applications: Multiple remote applications available based on Ethernet LAN and
windows platform, such as image centralized storage and identify, recheck workstation, and network TIP, etc.

Images process:
24bit real time processing ,4colors analysis, Images displayed marked date and ID NO ,Count the number of bags ,Memory gray level:65536



X-ray Generator



Generate direct: from bottom to top
Anode Voltage: 140-160kv operating
Cooling / Duty Cycle: Oil Cooling /100%



Computer Character



CASE: chassis ATX/Matx chassis
Power: 80+bronze ps/2 sps 300w ATX(DELTA)ROHS
Main board: H61,LAG 1155 Micro ATX,2VGA/LVDS/(DVI optional)/10*com/1*LPT/2GeLAN/PCI/
PCIe/AMP/10*USB
CPU: Celeron 2.5G 3m 1155p G540(G)
Storage: 2G DDR3-1333 240PIN 256X8 HYX(g)TS 5KNN 28100-3Y
Hard Disk : SEAGATE 500G 3.5” IDE 5KRPM(G)



Other Characters optional



1 Computer system: XP system or windows 7

2 UPS camera system and photographic system Optional
3 Support card reader operator access (optional)
4 CD DVR/RW unit: Optional
5 Extension Rollers: Optional (50cm length roller)
6 Monitor optional: 17 inch DELL brand or 19inch monitor



Operating Environment



Operation temperature/Humidity: 0℃-45℃/20%-95%(non-condensing)
Storage Temperature/Humidity: -40℃~+60℃ / 5%~95% (non-condensing)
Operation Power: 220VAC(±10%)50±3Hz (100VAC,110VAC,120VAC,200VAC)
Power Consumption: 1.0KW(working)
Noise: <58db




Why choose us?



  1. We have 20000 square meter factory, 4 floor, 260 employess and 5 R&D team
  2. We have passed ISO9001, 16001, OHSMS18001, Health Inspection
  3. We have full security product line which can meet your different needs
  4. We never stop researching and will have one or two new product each year
  5. We listen to our customer and solve their problems



Certifications:



1.CE Certificate

2.ISO9001 Certificate

3.ISO14001 Certificate

4.OHSMS18001 Certificate

5. USFDA Certificate

6.Radiation Safety Certificate From Chinese Government

7.Test Report From Inspection Center Of State Security Ministry





Patents:

1. Security equipment image data transmission system(patent no.: 201020700244.8)

2. One key switch off device for x ray device(patent no.: 201020700256.0)

3. Sensors device for security inspection(patent no.: 201020700245.2)

4. Dangerous liquid detecting circuit(patent no.: 201120107219.5)



Our Services:



1.Operation training program for end users

2.Free of factory training for engineer from agents to end user

3.Provide on-site trainning when customer requires

4.If quality problems happen in guarantee period, our company will maintain for free.

5.One year free spare parts and life time technical support

6.After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.

7.If you are caught in some problems when using our products, welcome to contact us at any time.



Wooden box packing for safe international shipment :

Custom Security X Ray Baggage Screening Equipment With TIP To Detect Explosive
