Product Details:

Place of Origin: China
Brand Name: SECUSCAN
Certification: CE, ISO, USFDA, Radiation Safety
Model Number: AT6040B

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Wooden Packing
Delivery Time: One week when there is stock, One month when no stock.
Payment Terms: T/T, L/C, Western Union
Supply Ability: 500 sets/month
Contact Now
Detailed Product Description
Operation: User Maual Attached With Machine Warranty: One Year Free Spare Parts, Life Time Technic Support
OEM/ODM: Accepted Installation: Very Easy, Only A Few Wires
Tunnel Size: 600(W)*400(H)mm Conveyor Speed: 0.22m/s
Penetration: 40-43mm Steel Software Interface: Support Multi Language
Training: Free Of Cost At The Factory Weight: 540kgs

Multi Language 0.22m / S Airport X Ray Machine With Tunnel Size 60*40cm



Advantages:

  • We have 20000 square meter factory, 4 floor, 260 employess and 5 R&D team
  • We have passed ISO9001, 16001, OHSMS18001, Health Inspection
  • We have full security product line which can meet your different needs
  • We never stop researching and will have one or two new product each year
  • We listen to our customer and solve their problems



X Ray Image:





X-ray Sensor L-Shaped Photodiode Array (multi-energetic), 12bit Deep
Monitor High Resolution Color, LCD Accord, 17 inch
Image Processing Edge enhancement, image strengthening, image lightening, , reducing darkening, image returning, image retrieval.
Image Grey Level 4096
Image Max Resolution 1024 * 1280 pixel
Image Processing 24bit for processing real time
Image storage Storage 60000 pictures in real time
Zoom 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation
Multi-energetic distinguish objects Organic objects in orange, inorganic objects in blue, mixture in green
High-energy/low energy Switch from high energy to low energy
Adavantage Assist to detect drug and explosive powder







X Ray Generator:



Beam direction Downward
Beam angle 80 degree
Anode voltage 140kv
Anode power 0.35mA
Cooling / Duty Cycle Oil Cooling /100%





General specification:



Tunnel Size 600(W)*400(H)mm
Conveyor Speed 0.22m/s
Conveyor Max Load 170kg
Dose per Inspection <1.5Gy/h
Resolution < 0.0787mm Copper Wire
Spatial Resolution Level Dia1.0mm
Vertical esolution Level: Dia1.0mm
Vertical: Dial1.0mm
Penetrate resolution 32-34mm
Film Safety Guarantee ISO1600 Film
X-ray Leakage <0.5 μ Gy/h (at a distance of 5cm From external housing)





Computer Specs:

  1. CPU: Intl Core 2 Duo 3400, 2.6GHz, 1MB, L2 Cache and 800Mhz FSB
  2. Motherboards: Intel G41/Nvidia chip set, 7025 or better on OEM motherboard
  3. Bus architecture: Integrated Graphics,5PCI, 1PCI Express *1 and 1PCI BX press *16
  4. Memory: 2GB 1333MHz DDR3 RAM, with Minimum2 total DIMM slots.
  5. Hard Disk drive: 500GB 7200 rpm serial ATA HDD.
  6. Mouse: Optical



Packing and Shipment:





Packing details carton packing, two cartons
Carton Size: (L)1800*(W)890*(H)1420mm
Total Gross Weight:540kg
Payment terms T/T, Western Union, Cash,L/C
Shipping methods By air (5-7days, most expensive)
By express (3-7days, more expensive)

By sea (15-28days, cheapest)







Installation Data:



  1. Operation temperature/Humidity: 0º C-45º C/20%-95%(non-condensing)
  2. Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
  3. Operation Power: 220VAC(± 10%)50± 3Hz
  4. Power Consumption: 1.0 KW (max), 0.7KW(working)
  5. Noise: <58dB.



Our service:



About quality:



We have below exact measures to assure you the quality, so you don't need to worry.


      1. All of our finished products will get passing the aging test to ensure reliability quality
      2. Quality inspection department will check the machine again before packing.
      3. We give one year warranty, provide spare parts free of cost for replacing the broken after delivery

About the after-sales service:

When there is any problems happened, our service team will fully assit you to solve the problem from several ways:

1. After-sales engineer will follow up all the way until the goods is installed and commissioning
2. Remote control the machine for diagnosing the problems
3. Technic support by video and telephone
4. Send engineer to your country for local support if necessary



About certification:



Our factory has ISO certificate, Radiation Safety certificte, BV certificate from Alibaba, SGS certificate from Made-in-china, CE certificate for our products.





Applications:





End user Recommend X Ray Baggage Scanner model NO.
Airports, Transport terminals AT6040; AT6550; AT10080; AT100100
Factories (to find needle in clothing,  shoes,  bags), AT5030; AT6040; AT6550
Courthouses, Embassies, Buildings AT5030; AT6040; AT6550
Military installations AT5030;AT6040; AT6550; AT8065; AT100100
Prisons, Hotels, Schools, Convention centers  AT5030; AT6040; AT6550; AT10080
Security checkpoints,Special events location  AT5030; AT6040; AT6550; AT8065; AT10080
