Walk Through digital Metal Detector Machine for security check-in Area

Walk Through digital Metal Detector Machine for security check-in Area

   Walkthrough Metal Detector can easily detect weapons, such as knife and gun, and any metal articles which are hidden in human body.

6 Pinpoint zones to precisely identify multiple target locations from head to toe.
Advanced broadband detection technology: can detect ferrous and non-ferrous articles.

Sensitivity adjustable from Level 0 to 1999

High: Can detect a pin
Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g),

ignoring metal in belt button, shoes.

Shock proof to avoid false alarm
Sound and light alarm
Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.

4 LED light bars on both door panels:gives alarm corresponding to the height or human body. LCD sreen show operate steps in English and Chinese
Tamper-Proof: operate program is protected by password.
Adjustable operating frequencies---eliminate the potential effects from X-ray units, radios and other electrical interference sources.

Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity

Harmless to pregnant woman and heart pacemaker


Specifications:

• Electric current: AC100V~240V   50/60Hz
• Power: 10W
• Work environment: -20℃~+45℃
• Gross Weight: 70kg
• Outer frame: 2220mm (h) x 820mm (w) X 610mm (d)
• Inner frame: 2000mm (h) X 700mm (w) X 610mm (d)

Applications:

• Commercial buildings; Factories(to find needle in clothing,  shoes,  bags)
• Courthouses; Embassies; Government buildings;
• Military installations; Prisons; Hotels;
• Schools; Convention centers; Security checkpoints.
• Excellent system for schools,  hotels,  convention centers and event-based security requirements

Competitive Advantage:

• High sensitivity,  economic model
• Suite for Airports, Banks, Embassies,  Jai house,
• Entertainment environments, Gymnasiums, Exhibition Centers etc
