Suitcase Inspection X Ray Baggage Scanner Machine for checking

China Suitcase Inspection X Ray Baggage Scanner Machine for checking supplier
Suitcase Inspection X Ray Baggage Scanner Machine for checking supplier Suitcase Inspection X Ray Baggage Scanner Machine for checking supplier Suitcase Inspection X Ray Baggage Scanner Machine for checking supplier Suitcase Inspection X Ray Baggage Scanner Machine for checking supplier Suitcase Inspection X Ray Baggage Scanner Machine for checking supplier

Large Image :  Suitcase Inspection X Ray Baggage Scanner Machine for checking

Product Details:

Place of Origin: China
Brand Name: SECUSCAN
Certification: CE, ISO
Model Number: AT6550

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD+1-6666+unit
Packaging Details: Wooden case Packing
Delivery Time: One week when there is stock, One month when no stock.
Payment Terms: T/T, L/C, Western Union
Supply Ability: 300 sets/month
Contact Now
Detailed Product Description
First Advantage: Integrated, Cost Effective, Turn-Key Security Fifth Advantage: Reliable Performance And Uncompromising Value
Sixth Advantage: Assist For Explosive And Drug Detection Second Advantage: Fit For Small Baggage And Parcel Security Inspection.
Third Advantage: Increased Detection Capability Fourth Advantage: Friendly Interface For Ease-of-use

Suitcase Inspection X Ray Baggage Scanner Machine for checking





SECU SCAN AT6550 is an advanced X ray scanner machine capable of detecting organic and inorganic items such as weapons,explosives and narcotics using different colour software which significantly enhances  the operator’s ability to identify suspicious item.



General Specifications:



Tunnel Size:

650(W)*500(H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

150kgs

Dose per Inspection:

<2.9 μGy/h

Resolution:

<0.101mm Metal Wire

Penetration:

32 mm Steel Standard, 34mm steel typical

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<0.05 μGy/h (at a distance of 5cm From external housing)

Generate direct:

Upward

Generate angle:

80 degree

Anode Voltage:

140Kv

Anode power:

0.4 to 1.2mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic),  12bit Deep

Monitor:

High Resolution Color,  LCD Accord,  17 inch





Image system parameters:



Image Processing:

Edge enhancement,  image strengthening,  image lightening,

reducing darkening,  image returning,  image retrieval.

Image Grey Level:

4096

Image Max Resolution:

1024 * 1280 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage 60000 pictures in real time

Zones & Zoom:

1-9 Image regions,  2, 4, 8, 16 Times Enlarge,

Whole screen continuous observation





Environmental parameters:



Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

1.1 KW (max),  0.3KW(working)

Noise:

<58db





Products Certifcations:

  1. Strict Quality Control, Double Test In Engineering And Producing
  2. Spare Parts Guaranteed
  3. High Performance Network
  4. Test Report From Inspection Center Of State Security Ministry
  5. CE Certificate
  6. ISO9001 Certificate
  7. ISO14001 Certificate
  8. Radiation Safety Certificate From Chinese Government



Packing and Shipping:

  • Wooden case packaging with size:
  • Scanner: 250(L)*110(W)*154(H)cm
  • Console: 74(L)*78(W)*137(H)cm
  • Gross weight: 700KG
  • Shipping by sea or air or express for your optional



SECU SCAN Service:



  1. Factory training free of cost for buyers.
  2. Engineer give online service from Chinese time: 8:30am to 21:30pm (Monday to Saturday)
  3. Our sales group also give service by e-mail in words or photos or vedio.
  4. We can send engineer to give local service for serious problem.
  5. One year free spare parts replacement. Life time technical support.

Company culture: Quality First and Service Foremost
