Product Details:
Place of Origin: CHINA
Brand Name: SECUSCAN
Certification: CE, ISO9001
Model Number: AT3300
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: wooden box
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 set per month
Detailed Product Description
Material: Stainless Steel Water Proof: IP68
Function: To Check Bomb In Vehicles Scanning Image: B/W, Color
Software: Multi-language Support Camera: Color
Technical Training: Free Warranty: 18 Months
High Light:

under vehicle monintor machine

,

car surveillance system



Stationary Vehicle Video Surveillance / under vehicle scanner system Number Plate Reading



Model : AT3300


     VSCAN AT3300 Under Vehicle Inspection System is the fixed solution for the fully identification of threats or modifications to a vehicle's undercarriage.
    It can quickly and accurately identify threats , contraband objects and stowaway who are hidden at the bottom. Vehicles drive over the embedded scanning units while VSCAN's systems compile high-resolution images of a vehicle's undercarriage to create the vehicle's fingerprint."


 Secuscan fixed AT3300 Under Vehicle Inspection System (UVIS) advantags :


a.) It can scan the undercarriage of all stationary vehicles and display the same on a screen

 located in the security booth for the duty SO’s inspection.  The capturerd picture can display

in full HD format with the level of quality that enables easy and quick visual inspection irrespective of the time of day or night or weather conditions;


b.) It can capture the whole undercarriage of a standard sedan, SUV, truck and bus;


c.) The store image of the undercarriage instantly at the SOC main server and keep an automatic back-up for the previous 30 days with an accurate time stamp;


d.) Be able to withstand the weight of a moving vehicle weighing up to 50 tonnes or be installed in a way that avoids a vehicle driving over the system;


e.) IP68 Waterproof and be able to maintain the same performance irrespective of temperature

 or weather conditions;



Main TechnicaIndexes of under vehicle system:


Embedded Screening Part


1. Camera: Sensor: line scans CCD, Resolution:
    5000*2048 pixels, Power Supply: 24VDC, 3A
2. Illumination: LED, Power Supply: 24VDC,150W
3. Size: 1200mm x 350mm4. Operating Temperature Range:-20 degree to +70 degree


Controller


1 Input: 2 channels induction coil
2 Output: 1 Channel switch type 12VDC
3 Communication port: RS485, Ethernet(Optional)
4 Operating Temperature: -10 degree to 50 degree

System Host
1 . Brand: Grantech (SYM76941VGGA)
2 . CPU: Intel(R)Celeron(R)CPU  E3400@2.6GHz 2.59 GHz
3 . Memory:2G( optional 4G)
4 . Graphics:512M
5 . Hard Disk:SATA2 Hard Disk 500G
6 . Dual LAN (At least one Intel Gigabit)
7 . USB2.0 (Up to 2 pieces)
8 . Monitor: 22inch LCD, resolution up to 1920*1080
9 . Scene Video Record: 4 channel, Compression algorithm of scene video: H264

 Optional :
*  ALPR-Automatic License Plate Recognition software : via IP Camera captures license plate, ALPR software processing and automatically presents license plate on screen
*  Driver Face Capture Camera : Provides picture of driver and/or view of vehicle. Image is presented on screen along with under vehicle images.
*  Screen Video display/DVR: displays live video feed from overview camera on operator terminal screen.

FAQ :

 Any interest, welcome to contact me for details .

Sunny ZHOU

Skype ID: secuscan03

Whatsapp/viber : +86-13510514294

AT3300 fixed UVSS/UVIS workshops
