Computed Tomography X Ray Baggage Scanner station security checking SPX-6550

China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
China SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED certification
I'm Online Chat Now

Computed Tomography X Ray Baggage Scanner station security checking SPX-6550

Computed Tomography X Ray Baggage Scanner station security checking SPX-6550
Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 Computed Tomography X Ray Baggage Scanner station security checking SPX-6550

Large Image :  Computed Tomography X Ray Baggage Scanner station security checking SPX-6550

Product Details:
Place of Origin: China
Brand Name: SECUPLUS
Certification: CE, ISO, FCC, ROHS
Model Number: SPX-6550
Port: Shenzhen
Brand: OEM accepted
ODM: ODM takes more time
Business Type: Manufacturer
Conveyor Speed;: 0.22m/s
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Packing
Delivery Time: One week when there is stock, One month when no stock.
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 sets/year
Detailed Product Description
Anode Voltage: 100~160Kv Tunnel Size: 650mm*500mm
Packing Details: Wooden Packing Delivery Detail: One Week Or One Month Depeeds OEM Or ODM
Conveyor Max Load: 170KG Service: Free Training In Factory, Technic Support Online
Penetration: 34mm Steel Film Safety Guarantee: ISO1600 Film
High Light:

airport screening machines

,

security screening equipment

Computed Tomography X Ray Baggage Scanner station security checking SPX-6550



Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 0

General Specification



Tunnel Size:

650(W)*500(H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

170kgs

Penetrate resolution

Dia 0.254mm

Resolution

< 0.0787mm Copper Wire

Penetration:

34 mm Steel

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<1μGy/h (at a distance of 5cm From external housing)

Pass rate:  720 bags per hour

Beam direction:

Diagonal

Generate angle:

80 degree

Anode Voltage:

100-160Kvadjustable

Anode power:

0.4 to 1.2mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic),  12bit Deep

Monitor:

High Resolution LCD Accord, 17 inch

Image Processing:

Edge enhancement,  image strengthening,  image lightening,

reducing darkening,  image returning,  image retrieval.

Image Grey Level:

4096

Image Max Resolution:

1024 * 768 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage 60000 pictures in real time

 Zoom:

max 16 Times Enlarge, Whole screen continuous observation

Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

1.0 KW (max), 0.7KW(working)

Noise:

58db



The SECUPLUS X Ray Baggage Scanner offers another way to see inside of handbags,briefcases. It popular accepted as a nonintrusively optimize security measure .


SPX5030C give you innovative and costeffective solutions. It¡s a great help to exclude the threats and contraband.


SPX6550 is friendly operation system, and easy to maintenance .


SECUPLUSis together with you to antiterrorism



Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 1

Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 2




Applications:


01.railway station
02. Transport terminals,
03. Buildings,
04. Factories (to find needle in clothing,  shoes,  bags),
05. Courthouses,
06. Embassies,
07. Military installations,
08. Prisons,
09. Hotels,
10. Schools ,
11. Convention centers,
12. Security checkpoints
13. Special events location





Our sevice

All products purchased in our company are guaranteed to keep in good repair for one year.

If quality problems happen in guarantee period, our company will maintain for free.

Additionally, our company provides technical support and fittings for life.

After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.

If you are caught in some problems when using our products, welcome to contact us at any time.



Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 3

Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 4



Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 5

Computed Tomography X Ray Baggage Scanner station security checking SPX-6550 6
