Color Scanning Images Displayed Under Vehicle Surveillance System

Color Scanning Images Displayed Under Vehicle Surveillance System
Color Scanning Images Displayed Under Vehicle Surveillance System Color Scanning Images Displayed Under Vehicle Surveillance System Color Scanning Images Displayed Under Vehicle Surveillance System

Large Image :  Color Scanning Images Displayed Under Vehicle Surveillance System

Product Details:
Place of Origin: China
Brand Name: VSCAN
Certification: CE and ISO
Model Number: AT3300
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: wooden packing
Delivery Time: 15days after confiming the orders
Payment Terms: Western Union, MoneyGram, L/C, T/T
Supply Ability: 50SETS/month
Detailed Product Description
Original Material: Stainless Steel Images: Color And B/W
Alarm: Light And Sound Waterproof: Support Weatherproof IP65
Network: Support Network Working
High Light:

under vehicle inspection systems

,

car surveillance system

Under Vehicle Surveillance System-Model: AT-3300





Vehicle security control at the entrances for find out explosives ,bombs and other danger objects .

Auto digital line scan, high-resolution undercarriage imaging.
High automation, easy to be used.
Applicable to variety of vehicles, wide vision.
Test will be completed during the vehicle maneuvers without stopping, adapted to different speed.
Undercarriage image can be stored, retrieved, searched or compared with other images.
A variety of image processing methods: enlarge, stretching and cutting.
Multi entrance management model, management, and statistics of entering and exiting vehicles.
Flexible detection process can be made on site to satisfy the needs of various work conditions.
Option of automatic number plate recognition system available, associative storage of various vehicle information and undercarriage images.
Image monitoring, video recording for different scenario.









Technical parameters:



  • Vertical resolution of the image: 5000*2048 pixels
  •  Check the width viewing angle: not less than 4 meters
  •  Speed of vehicle: < 30km/h with ALPR (Automatic License Plate Recognition)                                           < 70km/h without ALPR (Automatic License Plate Recognition)
  •  Effective field of view( FOV): less than 170°
  •  FOV inspecting width: < 4 meters
  •  Auxiliary light: 100W
  •  Weight capacity: <20T
  •  Water-proof grade: IP68
  •  Scanning device weight: <24KG
  •  Scanning device volume: 450mm×400mm×88mm
  •  Communication interface: RS232/RS422
  •  Operating Temperature: -20°c to 55°c
  •  Storage temperature: -20°c to +75°c
  •  Operating voltage: 110-240V AC, 50-60HZ







Color Scanning Images Displayed Under Vehicle Surveillance System 0
