Color Image X Ray Baggage Scanner

China Color Image X Ray Baggage Scanner supplier
Color Image X Ray Baggage Scanner supplier Color Image X Ray Baggage Scanner supplier Color Image X Ray Baggage Scanner supplier Color Image X Ray Baggage Scanner supplier

Large Image :  Color Image X Ray Baggage Scanner

Product Details:

Place of Origin: China
Brand Name: SECUSCAN
Certification: CE, ISO,US.FDA
Model Number: AT5030C

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 1-30000/unit
Packaging Details: Wooden box
Delivery Time: 14 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 500 sets/month
Contact Now
Detailed Product Description
Frame Material: Stainless Steel Images Storage: 100,000 Image
Software Interface: English, French, Russia, Spainish Alarm: Sound And Light Alarm
Warranty: 2 Years Converyor Load: 150kg
Software: English, Russian, French, Spainsh Display: 17" Monitor
Technical Support: Life Time Image: B/W, Color



Stainless Steel frame Color image X Ray Baggage Scanner for hotel, event, meeting center


     AT5030C with a high tunnel opening and a low conveyor, the SECUSCAN AT5030C is designed for easy loading and unloading of upright baggage. The AT5030C’s dual-energy detection provides provides material discrimination so that screeners can identify the material composition of a scanned object, while its compact footprint allows customers to make the most of the available space at a checkpoint.


Specifications:



Tunnel Size:

500(W)*300(H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

150kgs

Dose per Inspection:

<2.9 μGy/h

Resolution:

<0.101mm Metal Wire

Penetration:

32mm Steel

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<0.05 μGy/h (at a distance of 5cm From external housing)

Generate direct:

Upward

Generate angle:

80 degree

Anode Voltage:

140Kv

Anode power:

0.3mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic),  16bit Deep

Monitor:

High Resolution Color,  LCD Accord,  17 inch

Image Processing:

Edge enhancement,  image strengthening,  image lightening,
 reducing darkening,  image returning,  image retrieval.

Image Grey Level:

65536

Image Max Resolution:

1024 * 1280 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage 100,000 pictures in real time

 Zoom:

32 Times Enlarge, Whole screen continuous observation

Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

0.5KWA

Noise:

<65db



Other Characters



* Keyboard Protection: IP43

* Machine Protection: IP20

* Extension stainless steel Rollers: Optional

* Dual direction scanning

* UPS(Uninterrupted Power Supply): Optional

* monitor: 19 inch (optional)

* TIP function

* to connect network or PC



Our Services:



1. Factory training free of cost for buyers.

2. Engineer give online service from Chinese time: 8:30am to 21:30pm (Monday to Saturday)

3. Our sales group also give service by e-mail in words or photos or vedio.

4. We can send engineer to give local service for serious problem.

5. One year free spare parts replacement. Life time technical support.

We target to have zero unsolved problem. And we never give up a single customer.
