Product Details:
Payment & Shipping Terms:
|
| Big Tunnel Size: | 1 Meter(W)* 1 Meter(H) | Resolution: | 38AWG-40AWG |
|---|---|---|---|
| Penetration: | 28mm Steel Gurantee, 36mm Steel Optional | Conveyor Speed: | 0.22m/s |
| Conveyor Load: | 200KG | Service: | One Year Spare Parts In Free |
| High Light: | airport screening machines,security screening equipment |
||
19 inch LCD Accord X-ray Baggage Screening Equipment for Luggage
Special for big size baggage inspection scanner model AT100100
Suitable for airport, custom, train staion,checkpo
Quick detail
General Specification
| Tunnel Size: | 1000(W)*1000(H)mm |
| Conveyor Speed: | 0.22m/s |
| Conveyor Max Load: | 200kg |
| Wire Resolution: | 32AWG to 38AWG |
| Spatial resolution: | horizontal:1.3 or 1.0mm, vertical: 1.3 or 1.0mm, |
| Penetration: | 28 to 34mm Steel |
| Film Safety: | Guarantee ISO1600 Film |
| X-ray Leakage: | <1 μSv/h (at a distance of 5cm from external housing) |
| Pass rate: | 720 bags per hour |
X-ray Generator
| Beam direction: | Diagonal |
| Generate angle: | 80 degree |
| Anode Voltage: | 100Kv to 160Kv adjustable |
| Anode power: | 0.4 to 0.5mA |
| Cooling / Duty Cycle: | Oil Cooling /100% |
Installation Data
| Operation temperature/Humidity: | 0℃-45℃/20%-95%(non-condensing) |
| Storage Temperature/Humidity: | -20℃-60℃/20%-95%(non-condensing) |
| Operation Power: | 220VAC(±10%)50±3Hz |
| Power Consumption: | 1.0 KW (max), 0.7KW(working) |
| Noise: | <58db |
Image System
| X-ray Sensor: | L-Shaped Photodiode Array (multi-energetic) , 12bit Deep |
| Monitor: | High Resolution Color, LCD Accord, 19 inch |
| Image Processing: | Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning, image retrieval. |
| Image Grey Level: | 4096 |
| Image Processing: | 24bit for processing real time |
| Image storage: | Storage 60000 pictures in real time |
| Zoom: | max 16 Times Enlarge, Whole screen continuous observation |
Advantage:
1 Top Scanning ability
2 Stable and reliable: each machine had strict high and low temperature test, high humidity test, anti-shock test,MTBF 10000 hours
3 Automatic sensor roller (Optional)
4 Upgrade quality solution (Optional)
5 Assist of detecting organic and inorganic items such as
weapons, explosives and narcotics using different colour show
