Product Details:
Payment & Shipping Terms:
|
Tunnel Size(mm): | 600(L)*400(W) | Conveyor Speed(m/s: | 0.22 |
---|---|---|---|
Conveyor Max Load(kgs): | 170 | Penetration: | 38 Mm Steel |
Warranty: | 12 Months | In Stocks: | About 20 Units |
High Light: | security screening equipment,airport baggage scanner |
Intelligent X Ray Baggage Scanner SPX-6040 cm airport security equipment with TIP functions
How to support after sales?
-We have strong after sales team, which is around you in the whole 24 hours
1. Integrated, cost Effective, Turn-Key Security
2. Fit for small Baggage and Parcel Security Inspection.
3. Increased detection capability
4. Friendly interface for ease-of-use
General Specifications
|
|||
Tunnel size(mm)
|
600(L)*400(W)
|
||
Conveyor Speed(m/s)
|
0.22
|
||
Conveyor height(mm)
|
690
|
||
Conveyor Max Load(kgs)
|
170
|
||
X ray dose per each inspection
|
1.5 μGy
|
||
X ray leakage
|
<0.25 μGy / h
|
||
Penetration
|
38mm steel
|
||
Wire Resolution
|
dia 0.0787mm copper wire (AWG40)
|
||
Penetration Resolution
|
dia 0.202mm copper wire (AWG32) under three-step aluminum wedge 9.5mm, 15.9mm, 22.2mm
|
||
Spatial resolution:
|
Horizontal:dia1.0mm,Vertical: dia1.0mm
|
||
Power Consumption
|
max. 1KW
|
Physical Specifications
|
|||
Unit weight (kgs)
|
595
|
||
Unit size (mm)
|
2848.5(L)*1095(W)*1535.5(H)
|
||
after packed in wooden pallet -
|
|
||
Gross weight (kgs)
|
750
|
||
Packing size
|
#1: 213*121*179cm
|
||
|
#2: 115*90*142cm
|
